14
HCD-EP50
Adjustment Location and Connecting Points
– MAIN BOARD (Component Side) –
T8
AM Frequency
Coverage Adjustment
T1
AM IF Adjustment
AM Tracking Adjustment
{
TC1
T6
– MAIN BOARD (Conductor Side) –
TP
(FM VT)
TP
(AM VT)
U1
U2
L902
}
FM Tracking Adjustment
TC901
L901 FM Frequency Coverage Adjustment
