Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
39
HCD-EP50
DISPLAY HEADPHONE MAIN
R363 1-216-049-11 RES-CHIP 1K 5% 1/10W
R364 1-216-097-11 RES-CHIP 100K 5% 1/10W
R365 1-216-097-11 RES-CHIP 100K 5% 1/10W
R366 1-216-097-11 RES-CHIP 100K 5% 1/10W
R368 1-216-049-11 RES-CHIP 1K 5% 1/10W
R369 1-216-049-11 RES-CHIP 1K 5% 1/10W
R370 1-216-049-11 RES-CHIP 1K 5% 1/10W
R372 1-216-049-11 RES-CHIP 1K 5% 1/10W
R373 1-249-433-11 CARBON 22K 5% 1/4W
R380 1-216-081-00 METAL CHIP 22K 5% 1/10W
R382 1-247-887-00 CARBON 220K 5% 1/4W
R384 1-249-429-11 CARBON 10K 5% 1/4W
R386 1-216-295-11 SHORT 0
R387 1-249-417-11 CARBON 1K 5% 1/4W
R388 1-249-437-11 CARBON 47K 5% 1/4W
R389 1-249-429-11 CARBON 10K 5% 1/4W
R391 1-249-417-11 CARBON 1K 5% 1/4W
R392 1-249-417-11 CARBON 1K 5% 1/4W
R393 1-249-429-11 CARBON 10K 5% 1/4W
R394 1-216-001-00 METAL CHIP 10 5% 1/10W
(AEP, UK)
R395 1-216-295-11 SHORT 0
R396 1-216-295-11 SHORT 0
R701 1-249-407-11 CARBON 150 5% 1/4W
R702 1-249-407-11 CARBON 150 5% 1/4W
R703 1-249-407-11 CARBON 150 5% 1/4W
< SWITCH >
SW301 1-570-472-11 SWITCH, KEY BOARD (I/1)
SW302 1-570-472-11 SWITCH, KEY BOARD (TUNER)
SW303 1-570-472-11 SWITCH, KEY BOARD (TAPE)
SW304 1-570-472-11 SWITCH, KEY BOARD (CD)
SW305 1-570-472-11 SWITCH, KEY BOARD (PLAY MODE, RDS/DIR)
SW306 1-570-472-11 SWITCH, KEY BOARD (x)
SW307 1-570-472-11 SWITCH, KEY BOARD (X)
SW308 1-570-472-11 SWITCH, KEY BOARD (Y)
SW309 1-570-472-11 SWITCH, KEY BOARD (TUNER MEM, ENTER)
SW310 1-570-472-11 SWITCH, KEY BOARD (PRESET –)
SW311 1-570-472-11 SWITCH, KEY BOARD (PRESET +)
SW312 1-570-472-11 SWITCH, KEY BOARD (DISPLAY)
SW313 1-570-472-11 SWITCH, KEY BOARD (TUNING –, . m)
SW314 1-570-472-11 SWITCH, KEY BOARD (TUNING +, M >)
SW315 1-570-472-11 SWITCH, KEY BOARD (MUSIC MENU)
SW316 1-570-472-11 SWITCH, KEY BOARD (MEGA BASS)
SW317 1-570-472-11 SWITCH, KEY BOARD (z)
SW318 1-786-224-11 SW, SLIDE (MONO STEREO, ISS)
< VIBRATOR/IC/ROTARY ENCODER >
X301 1-795-436-11 VIBRATOR, CRYSTAL (4.194304MHz)
X302 8-749-016-29 IC RPM6938 (REMOTE CONTROL RECEIVER)
X303 1-476-916-11 ENCODER (VOLUME)
X304 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz) (AEP, UK)
**************************************************************
A-4727-040-A HEADPHONE BOARD, COMPLETE
***************************
< CAPACITOR >
C501 1-161-494-00 CERAMIC 0.022uF 25V
C502 1-161-494-00 CERAMIC 0.022uF 25V
< JACK >
JK401 1-815-813-11 JACK (LARGE TYPE) (PHONES)
< COIL >
L501 1-410-521-11 INDUCTOR 100uH
L502 1-410-521-11 INDUCTOR 100uH
L503 1-410-501-11 INDUCTOR 2.2uH
L504 1-410-521-11 INDUCTOR 100uH
**************************************************************
A-4727-039-A MAIN BOARD, COMPLETE (AEP, CH, UK)
A-4727-281-A MAIN BOARD, COMPLETE
(AR, CND, HK, MX, SP, US)
*********************
7-682-548-04 SCREW +B 3X8
< BAND PASS FILTER >
BPF901 1-234-704-11 FILTER, BAND PASS (FM)
(EXCEPT AEP, CH, UK)
< CAPACITOR >
C1 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
(AEP, CH, UK)
C2 1-126-935-11 ELECT 470uF 20% 16V
C3 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C4 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C5 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C6 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
(AEP, CH, UK)
C7 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
(AEP, CH, UK)
C8 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(AEP, CH, UK)
C9 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C10 1-126-967-11 ELECT 47uF 20% 50V
C11 1-115-870-11 ELECT 0.47uF 20% 50V
C12 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C13 1-126-794-11 ELECT 4.7uF 20% 50V
C14 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C15 1-126-514-11 ELECT 22uF 20% 16V
C16 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C17 1-126-933-11 ELECT 100uF 20% 16V
(AEP, CH, UK)
C18 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(AEP, CH, UK)
C19 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, CH, UK)
C20 1-130-483-00 MYLAR 0.01uF 5% 50V
C21 1-130-483-00 MYLAR 0.01uF 5% 50V
C22 1-126-514-11 ELECT 22uF 20% 16V
C23 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, CH, UK)
C24 1-126-961-11 ELECT 2.2uF 20% 50V
C25 1-126-961-11 ELECT 2.2uF 20% 50V
C26 1-130-479-00 MYLAR 0.0047uF 5% 50V
C27 1-130-479-00 MYLAR 0.0047uF 5% 50V
C28 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
Ver 1.1
