HCD-F200/F500
52
• IC Pin Function Description
MAIN BOARD IC101 R5F3640DDFAR (SYSTEM CONTROLLER)
Pin No. Pin Name I/O Description
1 SYS_RXD O Serial data output to the SYSTEM CONTROL connector (SA-WSF200/F500)
2 SYS_CLK O
Serial data transfer clock signal output to the SYSTEM CONTROL connector
(SA-WSF200/F500)
3 CEC_RX_IN I CEC serial data input from the HDMI OUT connector
4 SIRCS_IN I SIRCS signal input from the remote control receiver
5 CODEC_DO O Serial data output to the A/D, D/A converter
6 CODEC_DI I Serial data input from the A/D, D/A converter
7 CODEC_CLK O Serial data transfer clock signal output to the A/D converter, D/A converter
8 BYTE I External data bus width selection signal input terminal Fixed at "L" in this set
9 CNVSS I Processor mode switch input terminal
10 CODEC_PDN O Reset signal output to the A/D, D/A converter "L": reset
11 CODEC_CS O Chip select signal output to the A/D, D/A converter
12 RESET I
System reset signal input from the SYSTEM CONTROL connector (SA-WSF200/F500)
"L": reset
For several hundreds msec. after the power supply rises, "L" is input, then it change to "H"
13 XOUT O Main system clock output terminal (10 MHz)
14 VSS - Ground terminal
15 XIN I Main system clock input terminal (10 MHz)
16 VCC1 - Power supply terminal (+3.3V)
17 NMI I Non-maskable interrupt input terminal Fixed at "H" in this set
18 CODEC_INT I Interrupt signal input from the A/D, D/A converter
19, 20 - - Not used
21 DOUT_MUTE O Digital signal on/off control signal output terminal (F200)
22 CEC_TX_OUT O CEC serial data output to the HDMI OUT connector
23 VIDEO_MUTE 0 O Video signal input selection signal output terminal
24 - - Not used
25 V_SEL O Video signal input selection signal output terminal
26 BACKLIGHT_LED O LED drive signal output terminal
27 DMPORT_DET I Connect detection signal input from the DMPORT jack
28 VIDEO_MUTE1 O Video signal input selection signal output terminal
29 I2C_CLK I/O Two-way I2C clock bus terminal Not used
30 I2C_DATA I/O Two-way I2C data bus terminal Not used
31 DMPORT_TX_OUT O Serial data output to the DMPORT connector
32 DMPORT_RX_IN I Serial data input from the DMPORT connector
33 CLK1 - Not used
34 RTS1 - Not used
35 DVD_SID O Serial data output to the servo DSP
36 DVD_SOD I Serial data input from the servo DSP
37 DVD_SCO I Serial data transfer clock signal input from the servo DSP
38 SYS_WAKEUP O System wake up signal output to the SYSTEM CONTROL connector (SA-WSF200/F500)
39, 40 - - Not used
41 EPM - Not used
42 - - Not used
43 P_CONT_HDMI O HDMI control signal output terminal (F500)
44 P_CONT1 O Power on/off control signal output terminal "H": power on
45 - - Not used
46 FLASH_CE - Not used
47 P_CONT_FL O Power on/off control signal output terminal for the front panel section "H": power on
48 to 55 - - Not used
56 LED_1 O LED drive signal output terminal
57 LED_2 O LED drive signal output terminal
58 LED_3 O LED drive signal output terminal Not used
59 STBY_LED O LED drive signal output terminal Not used
60, 61 - - Not used
To Next Page
