HCD-F200/F500
53
Pin No. Pin Name I/O Description
62 VCC2 - Power supply terminal (+3.3V)
63 - - Not used
64 VSS - Ground terminal
65 - - Not used
66 FL_RESET O Reset signal output to the fl uorescent indicator tube driver "L": reset
67 FL_CLK O Serial data transfer clock signal output to the fl uorescent indicator tube driver
68 FL_D_OUT O Serial data output to the LED driver and fl uorescent indicator tube driver
69 FL_CS O Chip select signal output to the fl uorescent indicator tube driver
70 CDM_OPEN I Disc insert (8/12cm) detect switch input terminal "L": disc insert
71 MTK_RST O Reset signal output to the servo DSP and fl ash ROM "L": reset
72 DVD_XIFCS I Chip select signal input from the servo DSP
73 DVD_XIFBUSY O Busy signal output to the servo DSP
74 KEY_INT I Power key wakeup signal input terminal
75 RDS_CLK I
RDS serial data transfer clock signal input from the tuner (FM)
(F200: AEP and UK models/F500: Russian model)
76 TUNED I Tuning detection signal input from the tuner (FM) "L": tuned
77 ST_DI O Serial data output to the tuner (FM)
78 ST_CLK O Serial data transfer clock signal output to the tuner (FM)
79 ST_DO I Serial data input from the tuner (FM)
80 ST_CE O Serial chip enable signal output to the tuner (FM)
81 RDS_DATA I
RDS serial data input from the tuner (FM)
(F200: AEP and UK models/F500: Russian model)
82 to 86 TEST1 to TEST5 - Not used
87 to 91 - - Not used
92 MIC_SW I Audio code detection signal input from the ECM-AC2 jack
93 to 95 KEY0 to KEY2 I Front panel key input terminal (A/D input)
96 AVSS - Ground terminal
97 SYS_BUSY I Busy signal input from the SYSTEM CONTROL connector (SA-WSF200/F500)
98 VREF I Reference voltage (+3.3V) input terminal
99 AVCC - Power supply terminal (+3.3V)
100 SYS_TXD I Serial data input from the SYSTEM CONTROL connector (SA-WSF200/F500)
