SA-WSF200/WSF500/SS-CTF500/F500/TSF200/TSF500
34
Pin No. Pin Name I/O Description
69 GND - Ground terminal
70 DPSOC O Audio serial data output to the stream processor
71 DPSOD O Audio serial data output terminal Not used
72 VDDINT - Power supply terminal (+1.2V)
73 VDDEXT - Power supply terminal (+3.3V)
74 GND - Ground terminal
75 VDDINT - Power supply terminal (+1.2V)
76 GND - Ground terminal
77 DPSOE O Audio serial data output to the data selector (SA-WSF500 only)
78, 79 DPSIA, DPSIB I Audio serial data input from the digital audio interface receiver
80, 81 DPSIC, DPSID I Audio serial data input terminal Not used
82 DPSIE I Audio serial data input from the digital audio interface receiver
83 VDDINT - Power supply terminal (+1.2V)
84, 85 GND - Ground terminal
86 DPDVLRCK O L/R sampling clock signal output termnal
87 DPDVBCK O Bit clock signal output to the stream processor and data selector
88 DPLRCK I L/R sampling clock signal input from the digital audio interface receiver
89 DPBCK I Bit clock signal input from the digital audio interface receiver
90 VDDINT - Power supply terminal (+1.2V)
91, 92 GND - Ground terminal
93 VDDEXT - Power supply terminal (+3.3V)
94 DPFSCK I Audio clock signal input from the digital audio interface receiver
95 GND - Ground terminal
96 VDDINT - Power supply terminal (+1.2V)
97 NONAUDIO* I PCM audio data input from the digital audio interface receiver
98 SF_CE* - Not used
99 VDDINT - Power supply terminal (+1.2V)
100 GND - Ground terminal
101 VDDINT - Power supply terminal (+1.2V)
102 GND - Ground terminal
103 VDDINT - Power supply terminal (+1.2V)
104 GND - Ground terminal
105 VDDINT - Power supply terminal (+1.2V)
106 GND - Ground terminal
107, 108 VDDINT - Power supply terminal (+1.2V)
109 GND - Ground terminal
110 VDDINT - Power supply terminal (+1.2V)
111 GND - Ground terminal
112 VDDINT - Power supply terminal (+1.2V)
113 GND - Ground terminal
114 VDDINT - Power supply terminal (+1.2V)
115 GND - Ground terminal
116 VDDEXT - Power supply terminal (+3.3V)
117 GND - Ground terminal
118 VDDINT - Power supply terminal (+1.2V)
119 GND - Ground terminal
120 VDDINT - Power supply terminal (+1.2V)
121 RESET* I Reset signal input from the system controller "L": reset
122 SPIDS* I Device selection signal input from the system controller
123 GND - Ground terminal
124 VDDINT - Power supply terminal (+1.2V)
125 SPICLK I Serial data transfer clock signal input from the system controller
126 MISO O Serial data output to the system controller
127 MOSI I Serial data input from the system controller
128 GND - Ground terminal
129 VDDINT - Power supply terminal (+1.2V)
130 VDDEXT - Power supply terminal (+3.3V)
131 AVDD - Power supply terminal (+1.2V)
132 AVSS - Ground terminal
