Pin No. Pin Name I/O Description
133 GND - Ground terminal
134 CLKOUT O Local clock signal output terminal Not used
135 EMU* O Emulation status signal output terminal Not used
136 TDO O Test data output terminal Not used
137 TDI I Test data input terminal Not used
138 TRST* I Test reset signal input terminal Not used
139 TCK I Test clock signal input terminal Not used
140 TMS I Test mode select signal input terminal Not used
141 GND - Ground terminal
142 CLKIN I System clock input terminal (25 MHz)
143 XTAL O System clock output terminal (25 MHz)
144 VDDEXT - Power supply terminal (+3.3V)
