Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SA-WSF200/WSF500/SS-CTF500/F500/TSF200/TSF500
44
C726 1-126-964-11 ELECT 10uF 20% 50V
(SA-WSF500)
C727 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(SA-WSF500)
C728 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(SA-WSF500)
C729 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(SA-WSF500)
C730 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(SA-WSF500)
C731 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
(SA-WSF500)
C732 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
(SA-WSF500)
C733 1-126-916-11 ELECT 1000uF 20% 6.3V
(SA-WSF500)
C734 1-126-964-11 ELECT 10uF 20% 50V
(SA-WSF500)
C735 1-126-964-11 ELECT 10uF 20% 50V
(SA-WSF500)
C737 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(SA-WSF500)
C738 1-126-964-11 ELECT 10uF 20% 50V
(SA-WSF500)
C739 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(SA-WSF500)
C740 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(SA-WSF500)
C741 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(SA-WSF500)
C742 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(SA-WSF500)
C743 1-112-784-11 ELECT CHIP 220uF 20% 6.3V
(SA-WSF500)
C764 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(SA-WSF500)
C765 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(SA-WSF500)
C801 1-126-916-11 ELECT 1000uF 20% 6.3V
C802 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C804 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C806 1-126-933-11 ELECT 100uF 20% 16V
C807 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C808 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C809 1-126-916-11 ELECT 1000uF 20% 6.3V
C810 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C821 1-126-933-11 ELECT 100uF 20% 16V
C826 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C827 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C828 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C829 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C830 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C831 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C832 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C833 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C837 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C838 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C840 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C841 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C842 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C843 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C844 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C845 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C846 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C847 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C848 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C849 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C850 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C851 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C852 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C853 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C854 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C855 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C856 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C859 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C862 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C863 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C864 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C865 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C866 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C867 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C868 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C869 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C870 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C871 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C872 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C877 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C878 1-162-914-11 CERAMIC CHIP 9PF 0.5PF 50V
C879 1-162-914-11 CERAMIC CHIP 9PF 0.5PF 50V
C880 1-126-964-11 ELECT 10uF 20% 50V
C881 1-126-964-11 ELECT 10uF 20% 50V
C882 1-126-964-11 ELECT 10uF 20% 50V
C883 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN204 1-785-102-11 PIN, CONNECTOR (3.96mm PITCH) 4P
CN205 1-784-921-11 PIN, CONNECTOR 4P (SA-WSF200)
CN207 1-784-923-11 PIN, CONNECTOR 7P (SA-WSF500)
* CN501 1-564-243-11 PIN, CONNECTOR (3.96mm PITCH) 6P
(SA-WSF500)
CN531 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN551 1-564-704-41 PIN, CONNECTOR (SMALL TYPE) 2P
* CN552 1-564-241-11 PIN, CONNECTOR (3.96mm PITCH) 4P
(SA-WSF200)
CN602 1-784-926-11 PIN, CONNECTOR 11P
CN610 1-821-023-11 SOCKET, D-SUB CONNECTOR 25P
(SYSTEM CONTROL ONLY FOR HCD-F200)
(SA-WSF200)
CN610 1-821-023-11 SOCKET, D-SUB CONNECTOR 25P
(SYSTEM CONTROL ONLY FOR HCD-F500)
(SA-WSF500)
CN701 1-821-747-11 CONNECTOR, CARD EDGE 20P (L)
(EZW-RT10) (SA-WSF500)
< DIODE >
D301 6-500-885-01 DIODE P6SMBJ33A-5
D302 6-500-885-01 DIODE P6SMBJ33A-5
D321 6-500-885-01 DIODE P6SMBJ33A-5
D322 6-500-885-01 DIODE P6SMBJ33A-5
D381 6-500-885-01 DIODE P6SMBJ33A-5 (SA-WSF500)
D382 6-500-885-01 DIODE P6SMBJ33A-5 (SA-WSF500)
D401 6-500-885-01 DIODE P6SMBJ33A-5
D402 6-500-885-01 DIODE P6SMBJ33A-5
D491 6-501-774-01 DIODE MAZ8150G0LS0
D551 6-501-817-01 DIODE MA2J1110GLS0
AMP-DSP
