Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SA-WSF200/WSF500/SS-CTF500/F500/TSF200/TSF500
4545
D552 6-501-817-01 DIODE MA2J1110GLS0
D601 6-501-817-01 DIODE MA2J1110GLS0
D602 6-501-817-01 DIODE MA2J1110GLS0
D603 6-501-817-01 DIODE MA2J1110GLS0
D610 6-501-817-01 DIODE MA2J1110GLS0
< GROUND TERMINAL >
ET271 1-537-738-21 TERMINAL BOARD, GROUND
* ET301 1-780-408-11 TERMINAL
* ET401 1-780-408-11 TERMINAL
ET502 1-537-738-21 TERMINAL BOARD, GROUND
ET601 1-537-738-21 TERMINAL BOARD, GROUND
ET610 1-537-738-21 TERMINAL BOARD, GROUND
ET701 1-537-738-21 TERMINAL BOARD, GROUND (SA-WSF500)
ET801 1-537-738-21 TERMINAL BOARD, GROUND
< FILTER >
FL221 1-234-177-21 FILTER, CHIP EMI
< IC >
IC221 6-702-300-01 IC TK11118CSCL-G
IC222 6-706-492-01 IC TC7SHU04FU (T5RSOJF)
IC231 6-709-035-01 IC CXD9876R
IC271 6-709-035-01 IC CXD9876R
IC301 6-712-370-01 IC CXD9936TN
IC321 6-712-370-01 IC CXD9936TN
IC381 6-712-370-01 IC CXD9936TN (SA-WSF500)
IC401 6-712-370-01 IC CXD9936TN
IC610 6-703-238-01 IC TC7WZ34FK (TE85R)
IC611 A-1545-408-A IC R5F3640DDFAR (for SERVICE) (SA-WSF200)
IC611 A-1545-409-A IC R5F3640MDFAR (for SERVICE) (SA-WSF500)
IC613 6-708-922-01 IC PST3635NR
IC615 (Not supplied) IC S-24CS16A0I-J8T1G
IC701 6-805-692-01 IC LC890561W
IC702 6-706-492-01 IC TC7SHU04FU (T5RSOJF)
IC703 6-709-888-01 IC TC7WHU04FK (T5RSOYF (SA-WSF500)
IC704 6-707-800-01 IC SRC4182 (SA-WSF500)
IC705 6-707-800-01 IC SRC4182 (SA-WSF500)
IC706 6-707-870-01 IC TC74VHC157FT (EKJ) (SA-WSF500)
IC801 6-712-613-01 IC SI-3010KM-TLS
IC802 6-712-613-01 IC SI-3010KM-TLS
IC820 6-710-388-01 IC 74LVC1G79GW-125
IC821 6-709-759-01 IC ADSST-AVR-1115
IC822 6-704-099-01 IC TC7WZ08FK (TE85R)
< COIL >
L201 1-414-754-11 INDUCTOR 10uH
L202 1-414-754-11 INDUCTOR 10uH
L203 1-414-754-11 INDUCTOR 10uH
L221 1-414-754-11 INDUCTOR 10uH
L222 1-412-939-11 INDUCTOR 1uH
L231 1-414-754-11 INDUCTOR 10uH
L323 1-457-579-11 INDUCTOR 10uH
L383 1-457-579-11 INDUCTOR 10uH (SA-WSF500)
L403 1-457-579-11 INDUCTOR 10uH
L551 1-469-527-91 INDUCTOR 47uH
L552 1-414-754-11 INDUCTOR 10uH
L553 1-457-579-11 INDUCTOR 10uH
L701 1-414-754-11 INDUCTOR 10uH
L702 1-414-754-11 INDUCTOR 10uH
L703 1-469-525-91 INDUCTOR 10uH (SA-WSF500)
L704 1-414-398-11 INDUCTOR 10uH (SA-WSF500)
L705 1-414-754-11 INDUCTOR 10uH (SA-WSF500)
L706 1-414-754-11 INDUCTOR 10uH (SA-WSF500)
L707 1-414-754-11 INDUCTOR 10uH (SA-WSF500)
L721 1-414-754-11 INDUCTOR 10uH
< TRANSISTOR >
Q431 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q432 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q441 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q442 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q471 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
(SA-WSF500)
Q472 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
(SA-WSF500)
Q481 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q482 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q491 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q492 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q493 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q494 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q495 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q551 8-729-142-51 TRANSISTOR 2SD1616A-TP-LK
Q552 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q553 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q610 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q701 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(SA-WSF500)
Q702 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(SA-WSF500)
Q820 8-729-038-11 TRANSISTOR RT1P140C-TP-1
< RESISTOR >
R222 1-216-295-91 SHORT CHIP 0
R223 1-216-805-11 METAL CHIP 47 5% 1/10W
R224 1-216-857-11 METAL CHIP 1M 5% 1/10W
R225 1-216-809-11 METAL CHIP 100 5% 1/10W
R226 1-216-864-11 SHORT CHIP 0
R231 1-216-833-11 METAL CHIP 10K 5% 1/10W
R232 1-216-864-11 SHORT CHIP 0
R233 1-216-817-11 METAL CHIP 470 5% 1/10W
R234 1-216-805-11 METAL CHIP 47 5% 1/10W
R235 1-216-817-11 METAL CHIP 470 5% 1/10W
R236 1-216-805-11 METAL CHIP 47 5% 1/10W
R237 1-216-805-11 METAL CHIP 47 5% 1/10W
R238 1-216-805-11 METAL CHIP 47 5% 1/10W
R239 1-216-805-11 METAL CHIP 47 5% 1/10W
R240 1-216-805-11 METAL CHIP 47 5% 1/10W
R241 1-216-809-11 METAL CHIP 100 5% 1/10W
R242 1-216-805-11 METAL CHIP 47 5% 1/10W
R243 1-216-809-11 METAL CHIP 100 5% 1/10W
R244 1-216-864-11 SHORT CHIP 0
R245 1-216-833-11 METAL CHIP 10K 5% 1/10W
R246 1-216-864-11 SHORT CHIP 0
R271 1-216-833-11 METAL CHIP 10K 5% 1/10W
R272 1-216-864-11 SHORT CHIP 0
R273 1-216-817-11 METAL CHIP 470 5% 1/10W
R274 1-216-817-11 METAL CHIP 470 5% 1/10W
R275 1-216-833-11 METAL CHIP 10K 5% 1/10W
R276 1-216-805-11 METAL CHIP 47 5% 1/10W
Note 1: IC615 cannot exchange with single. When IC615
is damaged, exchange the entire mounted board.
AMP-DSP
Note 2: Refer to the Servicing Notes “BOND FIXATION OF ELECTRIC
PARTS” (page 4) when you exchange L323, L383, L403 and L553.
