145
STR-DA5200ES
USB BOARD IC006 TMP92FY23FG-06A3ES-USB-X100 (USB CONTROLLER)
Pin No.
Pin Name I/O Description
1
AVSS/VREFL - Ground terminal
2
AVCC/VREFH - Power supply terminal (+3.3 V)
3
PN3
(USB_ERROR)
- Not used
4
ST_REQ I Request signal input from the DSP
5
CONECT_DETC I USB connection detect signal input terminal
6
PN6
(USB_ERROR)
- Not used
7
IPOD_TX - Not used
8
IPOD_RX - Not used
9
NC - Not used
10
TXD1 O Serial data output terminal
11
RXD1 I Serial data input terminal
12
PN4 O Serial data output to the system controller
13 to 15
BUS0 to BUS2 O Bus data output to the DSP
16
IIC-DATA I/O Two-way data bus with the EEPROM
17
IIC-CLK O Serial data transfer clock signal output to the EEPROM
18
BUS3 O Bus data output to the DSP
19
PD0 (DI) I Serial data input from the system controller
20
DVSS - Ground terminal
21
UHC124_INT O Interrupt request signal output to the USB interface
22
DVCC - Power supply terminal (+3.3 V)
23 to 30
D0 to D7 I/O Two-way data bus with the USB interface and FCRAM
31 to 38
D8 to D15 I/O Two-way data bus with the FCRAM
39
DVSS - Ground terminal
40
NMI I Non-maskable interrupt input Fixed at "H" in this set
41
DVCC - Power supply terminal (+3.3 V)
42 to 60
A0 to A18 O Address signal output to the FCRAM
61
USB ERROR O Error signal output to the system controller
62
BUCK O Bus clock signal output to the DSP
63
PF5 (CCE) O Chip enable signal output to the DSP
64
ZIPANG_RST O Reset signal output to the DSP
65
GATE O Muting on/off control signal output to the DSP "L": mute
66 BOOT O
Boot mode control signal output terminal
67 USB_CS O
Chip select signal output to the USB interface
68 SRAM_CS1 O
Chip select signal output to the FCRAM
69 SRAM_CS2 O
Chip select signal output terminal Not used
70 CLK_IN I
Bit clock signal (2.8224 MHz) input terminal
71
DATA O Digital audio data output to the DSP
72
AM1 - Not used
73
X2 O System clock output terminal (10 MHz)
74
DVSS - Ground terminal
75
X1 I System clock input terminal (10 MHz)
76
DVCC - Power supply terminal (+3.3 V)
77
USBSYS_RST I Reset signal output to the USB interface
78
AM0 - Not used
