Sony STR-DA5200ES Service Manual

96
STR-DA5200ES
– VIDEO Board –
uj
IC6702 qg (CH3IN2)
(VIDEO 1 mode)
200 mV/DIV, 20 µ s/DIV
H
0.5 Vp-p
uk
IC6702 w; (CH3OUT)
(VIDEO 1 mode)
500 mV/DIV, 20 µ s/DIV
H
1.1 Vp-p
uf
IC6702 1 (CH1IN1)
(VIDEO 1 mode)
500 mV/DIV, 20 µ s/DIV
H
0.8 Vp-p
ug
IC6702 3 (CH1IN2)
(VIDEO 1 mode)
500 mV/DIV, 20 µ s/DIV 500 mV/DIV, 20 µ s/DIV
500 mV/DIV, 20
µ s/DIV
H
0.8 Vp-p
id
IC6402 qd (V1.IN)
(VIDEO 1 mode)
500 mV/DIV, 20 µ s/DIV
H
0.9 Vp-p
ua
IC6701 3 (CR IN)
(VIDEO 1 mode)
200 mV/DIV, 20 µ s/DIV
H
0.4 Vp-p
us
IC6701 5 (CB IN)
(VIDEO 1 mode)
200 mV/DIV, 20 µ s/DIV
H
0.4Vp-p
ud
IC6701 7 (Y IN)
(VIDEO 1 mode)
500 mV/DIV, 20 µ s/DIV
H
0.7 Vp-p
i;
IC6702 wf (CH1OUT)
(VIDEO 1 mode)
500 mV/DIV, 20 µ s/DIV
H
H
H
1.6 Vp-p
ia
IC6401 qd (V1.IN)
(VIDEO 1 mode)
0.9 Vp-p
is
IC6402 1 (M.OUT)
(VIDEO 1 mode)
1.8 Vp-p
ul
IC6702 ws (CH2OUT)
(VIDEO 1 mode)
500 mV/DIV, 20 µ s/DIV
H
1.4 Vp-p
uh
IC6702 q; (CH2IN2)
(VIDEO 1 mode)
500 mV/DIV, 20 µ s/DIV
H
0.7 Vp-p
