145
GB
Additional Information
Reference sections
To clear the memory of the
simple remote control
After removing the batteries, do not use the
remote control for a few minutes.
If the buttons on the receiver or the remote
control do not work due to a malfunction of the
receiver, reboot the receiver.
Hold down ?/1 for 10 seconds.
When the lamp above ?/1 flashes in green, the
reboot starts.
Refer to the following web site for details of
the latest information on the receiver.
http://support.sony-europe.com/
Specifications
Amplifier section
POWER OUTPUT
1) 2)
Rated Power Output at Stereo Mode
(8 ohms 20 Hz – 20 kHz,
THD 0.09%):
120 W + 120 W
Reference Power Output at Stereo Mode
(4 ohms 20 Hz – 20 kHz,
THD 0.15%):
120 W + 120 W
Reference Power Output
(8 ohms 1 kHz, THD 0.7%)
FRONT:
130 W + 130 W
FRONT HIGH:
130 W + 130 W
CENTER: 130 W
SURROUND:
130 W + 130 W
SURROUND BACK:
130 W + 130 W
Reference Power Output
(4 ohms 1 kHz, THD 0.7%)
FRONT:
120 W + 120 W
FRONT HIGH:
120 W + 120 W
CENTER: 120 W
SURROUND:
120 W + 120 W
SURROUND BACK:
120 W + 120 W
1)
Measured under the following conditions:
Power requirements: 230 V AC, 50/60 Hz
2)
Depending on the sound field settings and the
source, there may be no sound output.
Frequency response
3)
Clearing the memory
To clear See
All memorized settings page 89
Memory of the multifunction
remote control
page 130
Rebooting the receiver
About support information
PHONO RIAA equalization
curve ± 1.0 dB (20 Hz –
20 kHz)
MULTI CHANNEL
INPUT, SA-CD/CD,
MD/TAPE, TV,
VIDEO 1/2, DVD, SAT/
CATV, GAME
10 Hz – 100 kHz
± 3 dB
continued
