Rear panel
A (USB) port (page 41)
B RS232C port
Used for maintenance and service.
C ANTENNA section
AM ANTENNA jack
(page 42)
FM ANTENNA jack
(page 42)
D LAN ports (switching hubs)
(page 44)
E DIGITAL INPUT/OUTPUT section
OPTICAL IN jacks
(page 29, 33, 34)
COAXIAL IN jacks
(page 32, 39)
HDMI IN/OUT* jacks
(page 29, 31, 33, 34)
F COMPONENT VIDEO INPUT/
OUTPUT section (page 29, 32, 34)
Y, P
B
, P
R
IN/OUT* jacks
G SPEAKERS section (page 27)
