70
GB
Note
You can connect the HDMI ZONE 2 OUT jack directly to a TV in zone 2 (without any amplifier/receiver). It
is recommended, however, that you connect a TV via an amplifier/receiver for higher audio/video capabilities,
reducing possible effects on the main zone. When you select the same HDMI input for both the main zone and
zone 2, the audio/video capabilities in the main zone will be limited in accordance with those in zone 2.
2: Zone 3 connections
BB
C
STR-DA5800ES
Main zone Zone 3
A IR repeater (not supplied)
B Speakers
C Other amplifier/receiver
Multifunction remote control
A
IR REMOTE IN
ZONE 3 AUDIO OUT
