Sony STR-DB870 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
61
STR-DB870/DB1070
A-4476-487-A BIAS BOARD, COMPLETE (DB870: AEP, UK)
A-4476-499-A BIAS BOARD, COMPLETE (US)
A-4476-512-A BIAS BOARD, COMPLETE
(CH, E2, E3, KR, MY, SP, TW)
A-4476-528-A BIAS BOARD, COMPLETE (DB1070: AEP, UK)
A-4476-840-A BIAS BOARD, COMPLETE (DB870: CND)
A-4476-841-A BIAS BOARD, COMPLETE (DB1070: CND)
*********************
< CAPACITOR >
C413 1-128-813-11 CERAMIC 220PF 5% 50V
C415 1-136-153-00 FILM 0.01uF 5% 50V
C416 1-119-824-11 ELECT MELF 10uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C416 1-135-743-11 ELECT 10uF 50V
(DB1070: AEP, UK)
C440 1-128-840-11 ELECT 47uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C440 1-135-708-11 ELECT 47uF 16V
(DB1070: AEP, UK)
C463 1-128-813-11 CERAMIC 220PF 5% 50V
C465 1-136-153-00 FILM 0.01uF 5% 50V
C466 1-119-824-11 ELECT MELF 10uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C466 1-135-743-11 ELECT 10uF 50V
(DB1070: AEP, UK)
C490 1-128-840-11 ELECT 47uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C490 1-135-708-11 ELECT 47uF 16V
(DB1070: AEP, UK)
C513 1-128-813-11 CERAMIC 220PF 5% 50V
C515 1-136-153-00 FILM 0.01uF 5% 50V
C516 1-119-824-11 ELECT MELF 10uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C516 1-135-743-11 ELECT 10uF 50V
(DB1070: AEP, UK)
C540 1-128-840-11 ELECT 47uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C540 1-135-708-11 ELECT 47uF 16V
(DB1070: AEP, UK)
C563 1-128-813-11 CERAMIC 220PF 5% 50V
C565 1-136-153-00 FILM 0.01uF 5% 50V
C566 1-119-824-11 ELECT MELF 10uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C566 1-135-743-11 ELECT 10uF 50V
(DB1070: AEP, UK)
C590 1-128-840-11 ELECT 47uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C590 1-135-708-11 ELECT 47uF 16V
(DB1070: AEP, UK)
C613 1-128-813-11 CERAMIC 220PF 5% 50V
C615 1-136-153-00 FILM 0.01uF 5% 50V
C616 1-119-824-11 ELECT MELF 10uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C616 1-135-743-11 ELECT 10uF 50V
(DB1070: AEP, UK)
C640 1-128-840-11 ELECT 47uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C640 1-135-708-11 ELECT 47uF 16V
(DB1070: AEP, UK)
C663 1-128-813-11 CERAMIC 220PF 5% 50V
(DB1070)
C665 1-136-153-00 FILM 0.01uF 5% 50V
(DB1070)
C666 1-119-824-11 ELECT MELF 10uF 20% 50V
(DB1070: CH, CND, E, US)
C666 1-135-743-11 ELECT 10uF 50V
(DB1070: AEP, UK)
C690 1-128-840-11 ELECT 47uF 20% 16V
(DB1070: CH, CND, E, US)
C690 1-135-708-11 ELECT 47uF 16V
(DB1070: AEP, UK)
C805 1-135-655-11 ELECT 470uF 6.3V
(DB1070: AEP, UK)
C805 1-137-657-11 ELECT 470uF 20% 6.3V
(DB870/DB1070: CH, CND, E, US)
C806 1-128-805-11 CERAMIC 47PF 5% 50V
C807 1-126-965-11 ELECT 22uF 20% 50V
C808 1-128-805-11 CERAMIC 47PF 5% 50V
< CONNECTOR >
CN401 1-784-923-11 PIN, CONNECTOR 7P
CN451 1-784-923-11 PIN, CONNECTOR 7P
CN501 1-784-923-11 PIN, CONNECTOR 7P
CN551 1-784-923-11 PIN, CONNECTOR 7P
CN601 1-784-923-11 PIN, CONNECTOR 7P
CN651 1-784-923-11 PIN, CONNECTOR 7P
CN809 1-779-977-11 PIN, CONNECTOR 6P
< DIODE >
D405 8-719-911-19 DIODE 1SS199-25
D406 8-719-911-19 DIODE 1SS199-25
D455 8-719-911-19 DIODE 1SS199-25
D456 8-719-911-19 DIODE 1SS199-25
D505 8-719-911-19 DIODE 1SS199-25
D506 8-719-911-19 DIODE 1SS199-25
D555 8-719-911-19 DIODE 1SS199-25
D556 8-719-911-19 DIODE 1SS199-25
D605 8-719-911-19 DIODE 1SS199-25
D606 8-719-911-19 DIODE 1SS199-25
D655 8-719-911-19 DIODE 1SS199-25 (DB1070)
D656 8-719-911-19 DIODE 1SS199-25 (DB1070)
D805 8-719-911-19 DIODE 1SS199-25
D806 8-719-911-19 DIODE 1SS199-25
D807 8-719-911-19 DIODE 1SS199-25
D808 8-719-911-19 DIODE 1SS199-25
D817 8-719-911-19 DIODE 1SS199-25
< IC >
IC803 8-759-636-74 IC M5218AP-22
< TRANSISTOR >
Q404 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q405 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q406 8-729-281-53 TRANSISTOR 2SC1815-GR
Q440 8-729-026-08 TRANSISTOR 2SC4495
Q454 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q455 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
BIAS
