Sony STR-DB870 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
63
STR-DB870/DB1070
R641 1-249-417-11 CARBON 1K 5% 1/4W
R642 1-249-429-11 CARBON 10K 5% 1/4W
R665 1-249-425-11 CARBON 4.7K 5% 1/4W
(DB1070)
0 R666 1-240-855-11 CARBON 6.2K 5% 1/4W F
(DB1070)
R668 1-249-420-11 CARBON 1.8K 5% 1/4W
(DB1070)
R669 1-249-431-11 CARBON 15K 5% 1/4W
(DB1070)
R670 1-249-439-11 CARBON 68K 5% 1/4W
(DB1070)
R671 1-247-866-11 CARBON 30K 5% 1/4W
(DB1070)
R672 1-247-843-11 CARBON 3.3K 5% 1/4W
(DB1070: AEP, UK)
R672 1-249-425-11 CARBON 4.7K 5% 1/4W
(DB1070: CND, US)
R672 1-249-429-11 CARBON 10K 5% 1/4W
(DB1070: CH, E)
R674 1-249-431-11 CARBON 15K 5% 1/4W
(DB1070)
R675 1-249-437-11 CARBON 47K 5% 1/4W
(DB1070)
R676 1-249-437-11 CARBON 47K 5% 1/4W
(DB1070)
R677 1-249-433-11 CARBON 22K 5% 1/4W
(DB1070)
R690 1-249-425-11 CARBON 4.7K 5% 1/4W
(DB1070)
R691 1-249-417-11 CARBON 1K 5% 1/4W
(DB1070)
R692 1-249-429-11 CARBON 10K 5% 1/4W
(DB1070)
R801 1-249-433-11 CARBON 22K 5% 1/4W
R802 1-249-417-11 CARBON 1K 5% 1/4W
R803 1-249-433-11 CARBON 22K 5% 1/4W
(DB870)
R803 1-249-435-11 CARBON 33K 5% 1/4W
(DB1070)
R804 1-249-429-11 CARBON 10K 5% 1/4W
R805 1-249-429-11 CARBON 10K 5% 1/4W
R806 1-249-436-11 CARBON 39K 5% 1/4W
R807 1-249-427-11 CARBON 6.8K 5% 1/4W
R819 1-249-429-11 CARBON 10K 5% 1/4W
R857 1-249-429-11 CARBON 10K 5% 1/4W
R858 1-247-895-00 CARBON 470K 5% 1/4W
R863 1-249-433-11 CARBON 22K 5% 1/4W
**************************************************************
1-681-092-11 DC1 BOARD
**********
1-533-217-31 HOLDER, FUSE (CND, US)
< CAPACITOR >
C915 1-125-895-11 ELECT 12000uF 20% 71V
(DB870)
C915 1-137-666-12 ELECT 15000uF 20% 71V
(DB1070)
C916 1-125-895-11 ELECT 12000uF 20% 71V
(DB870)
C916 1-137-666-12 ELECT 15000uF 20% 71V
(DB1070)
C917 1-137-350-11 MYLAR 0.015uF 10% 100V
(AEP, CH, E, UK)
C917 1-137-419-11 MYLAR 0.033uF 10% 100V
(CND, US)
C918 1-137-350-11 MYLAR 0.015uF 10% 100V
(AEP, CH, E, UK)
C918 1-137-419-11 MYLAR 0.033uF 10% 100V
(CND, US)
C919 1-104-999-11 MYLAR 0.1uF 10% 200V
(AEP, CH, E, UK)
< DIODE >
D914 8-719-072-05 DIODE RBV-602LF-A
< FUSE >
0 F905 1-533-311-11 FUSE GLASS CYLINDRICAL (DIA.5) (8A/125V)
(CND, US)
0 F906 1-533-311-11 FUSE GLASS CYLINDRICAL (DIA.5) (8A/125V)
(CND, US)
< RESISTOR >
0 R913 1-249-407-11 CARBON 150 5% 1/4W F
(AEP, CH, E, UK)
**************************************************************
A-4476-476-A DC2 BOARD, COMPLETE (DB870: CND)
A-4476-491-A DC2 BOARD, COMPLETE (DB870: AEP, UK)
A-4476-504-A DC2 BOARD, COMPLETE (US)
A-4476-515-A DC2 BOARD, COMPLETE
(CH, E2, E3, KR, MY, SP, TW)
A-4476-529-A DC2 BOARD, COMPLETE (DB1070: AEP, UK)
A-4726-835-A DC2 BOARD, COMPLETE (DB1070: CND)
********************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C901 1-104-660-11 ELECT 47uF 20% 16V
C902 1-127-732-51 ELECT MELF 2200uF 20% 35V
(DB870/DB1070: CH, CND, E, US)
C902 1-135-781-51 ELECT 2200uF 35V
(DB1070: AEP, UK)
C903 1-127-731-51 ELECT MELF 1000uF 20% 35V
(DB870/DB1070: CH, CND, E, US)
C903 1-135-780-51 ELECT 1000uF 35V
(DB1070: AEP, UK)
C904 1-126-967-11 ELECT 47uF 20% 50V
C905 1-104-660-11 ELECT 47uF 20% 16V
C906 1-126-967-11 ELECT 47uF 20% 50V
C907 1-127-723-51 ELECT MELF 4700uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C907 1-135-696-11 ELECT 4700uF 16V
(DB1070: AEP, UK)
C908 1-126-767-11 ELECT 1000uF 20% 16V
C909 1-128-554-11 ELECT 330uF 20% 63V
C912 1-104-660-11 ELECT 47uF 20% 16V
BIAS DC1 DC2
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
