Sony STR-DB870 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
65
STR-DB870/DB1070
C1204 1-127-719-11 ELECT MELF 220uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C1204 1-135-710-11 ELECT 220uF 16V
(DB1070: AEP, UK)
C1205 1-119-824-11 ELECT MELF 10uF 20% 50V
(DB1070: AEP, CH, E, UK)
C1205 1-135-743-11 ELECT 10uF 50V
(DB1070: AEP, UK)
C1206 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DB1070)
C1207 1-119-824-11 ELECT MELF 10uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C1207 1-135-743-11 ELECT 10uF 50V
(DB1070: AEP, UK)
C1208 1-119-824-11 ELECT MELF 10uF 20% 50V
(DB1070: US, CND, E, CH)
C1208 1-135-743-11 ELECT 10uF 50V
(DB1070: AEP, UK)
C1210 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1211 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1212 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DB1070)
C1213 1-119-824-11 ELECT MELF 10uF 20% 50V
(DB1070: US, CND, E, CH)
C1213 1-135-743-11 ELECT 10uF 50V
(DB1070: AEP, UK)
C1214 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C1221 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C1221 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C1222 1-163-012-00 CERAMIC CHIP 0.0018uF 5% 50V
C1223 1-163-257-11 CERAMIC CHIP 180PF 5% 50V
C1224 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C1224 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C1231 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C1231 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C1232 1-163-012-00 CERAMIC CHIP 0.0018uF 5% 50V
C1233 1-163-257-11 CERAMIC CHIP 180PF 5% 50V
C1234 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C1234 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C1241 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C1241 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C1242 1-163-012-00 CERAMIC CHIP 0.0018uF 5% 50V
C1243 1-163-257-11 CERAMIC CHIP 180PF 5% 50V
C1244 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C1244 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C1251 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C1251 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C1252 1-163-012-00 CERAMIC CHIP 0.0018uF 5% 50V
C1253 1-163-257-11 CERAMIC CHIP 180PF 5% 50V
C1254 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C1254 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C1261 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C1261 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C1262 1-163-012-00 CERAMIC CHIP 0.0018uF 5% 50V
C1263 1-163-257-11 CERAMIC CHIP 180PF 5% 50V
C1264 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C1264 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C1271 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C1271 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C1272 1-163-012-00 CERAMIC CHIP 0.0018uF 5% 50V
C1273 1-163-257-11 CERAMIC CHIP 180PF 5% 50V
C1274 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C1274 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C1281 1-128-858-11 ELECT 22uF 20% 50V
(DB1070: CH, CND, E, US)
C1281 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C1282 1-163-012-00 CERAMIC CHIP 0.0018uF 5% 50V
(DB1070)
C1283 1-163-257-11 CERAMIC CHIP 180PF 5% 50V
(DB1070)
C1284 1-128-858-11 ELECT 22uF 20% 50V
(DB1070: CH, CND, E, US)
C1284 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C1306 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1307 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1308 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1309 1-127-718-11 ELECT MELF 100uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C1309 1-135-709-11 ELECT 100uF 16V
(DB1070: AEP, UK)
C1310 1-127-718-11 ELECT MELF 100uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C1310 1-135-709-11 ELECT 100uF 16V
(DB1070: AEP, UK)
C1313 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
(AEP, UK)
C1314 1-163-249-11 CERAMIC CHIP 82PF 5% 50V
(AEP, UK)
C1315 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(AEP, UK)
C1316 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
(AEP, UK)
C1317 1-119-824-11 ELECT MELF 10uF 20% 50V
(DB870: AEP, UK)
C1317 1-135-743-11 ELECT 10uF 50V
(DB1070: AEP, UK)
DIGITAL
