Sony STR-DB870 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
67
STR-DB870/DB1070
C1716 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1717 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1718 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1719 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1720 1-163-021-11 CERAMIC CHIP 0.001uF 10% 50V
C1721 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1722 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1723 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1724 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1725 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1726 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1727 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1728 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1801 1-127-718-11 ELECT MELF 100uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C1801 1-135-709-11 ELECT 100uF 16V
(DB1070: AEP, UK)
C1802 1-127-720-11 ELECT MELF 470uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C1802 1-135-711-11 ELECT 470uF 16V
(DB1070: AEP, UK)
C1807 1-127-719-11 ELECT MELF 220uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C1807 1-135-710-11 ELECT 220uF 16V
(DB1070: AEP, UK)
C1808 1-127-720-11 ELECT MELF 470uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C1808 1-135-711-11 ELECT 470uF 16V
(DB1070: AEP, UK)
C1809 1-127-720-11 ELECT MELF 470uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C1809 1-135-711-11 ELECT 470uF 16V
(DB1070: AEP, UK)
C1811 1-119-841-11 ELECT 1000uF 20% 63V
(DB1070: AEP, UK)
C1811 1-127-721-11 ELECT 1000uF 20% 16V
(DB870/EXCEPT DB1070: AEP, UK)
C1812 1-137-661-11 ELECT 4700uF 20% 6.3V
C1815 1-119-841-11 ELECT 1000uF 20% 63V
(DB1070: AEP, UK)
C1815 1-127-721-11 ELECT 1000uF 20% 16V
(DB870/EXCEPT DB1070: AEP, UK)
< CONNECTOR >
CN1101 1-784-753-11 CONNECTOR, FFC 31P
CN1102 1-569-815-11 CONNECTOR, BOARD TO BOARD 21P
CN1103 1-569-815-11 CONNECTOR, BOARD TO BOARD 21P
CN1104 1-568-830-11 CONNECTOR, FFC 11P (DB870: AEP, UK)
CN1104 1-568-838-11 CONNECTOR, FFC 21P (CND, US)
CN1104 1-784-776-11 CONNECTOR, FFC 15P
(DB1070: AEP, CH, E, UK)
CN1105 1-784-776-11 CONNECTOR, FFC 15P
CN1106 1-779-799-11 PIN, CONNECTOR 9P
CN1107 1-784-923-11 PIN, CONNECTOR 7P
CN1108 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< DIODE >
D1701 8-719-988-61 DIODE 1SS355TE-17
D1702 8-719-988-61 DIODE 1SS355TE-17
D1703 8-719-801-78 DIODE 1SS184
D1801 8-719-053-18 DIODE 1SR154-400TE-25
D1802 8-719-988-61 DIODE 1SS355TE-17
D1803 8-719-053-18 DIODE 1SR154-400TE-25
< FERRITE BEAD >
FB1101 1-469-730-11 FERRITE 0uH
FB1102 1-469-152-11 FERRITE 0uH
FB1201 1-469-152-11 FERRITE 0uH
FB1202 1-469-152-11 FERRITE 0uH
FB1401 1-469-152-11 FERRITE 0uH
FB1402 1-469-152-11 FERRITE 0uH
FB1403 1-469-152-11 FERRITE 0uH
FB1404 1-469-152-11 FERRITE 0uH
FB1405 1-469-730-11 FERRITE 0uH
FB1406 1-469-730-11 FERRITE 0uH
FB1407 1-469-730-11 FERRITE 0uH
FB1501 1-469-152-11 FERRITE 0uH
FB1502 1-469-152-11 FERRITE 0uH
FB1601 1-469-730-11 FERRITE 0uH
FB1602 1-469-152-11 FERRITE 0uH
FB1603 1-469-152-11 FERRITE 0uH
FB1604 1-469-730-11 FERRITE 0uH
FB1703 1-469-152-11 FERRITE 0uH
< IC >
IC1101 8-759-560-56 IC PCM1800E/2K
IC1102 8-759-099-06 IC M5218AFP-TE1
IC1201 8-759-825-12 IC PCM1604Y/2K
IC1202 8-759-825-13 IC PCM1748E/2K (DB1070)
IC1221 8-759-099-06 IC M5218AFP-TE1
IC1241 8-759-099-06 IC M5218AFP-TE1
IC1261 8-759-099-06 IC M5218AFP-TE1
IC1281 8-759-099-06 IC M5218AFP-TE1 (DB1070)
IC1301 8-759-231-58 IC TA7812S
IC1302 8-759-445-59 IC BA033T
IC1303 8-759-557-36 IC BU1924F-E2 (AEP, UK)
IC1401 8-749-017-36 IC TORX-179 (DIGITAL DVD/LD OPTICAL IN)
IC1402 8-749-923-05 IC TORX178B (DIGITAL TV/SAT OPTICAL IN)
IC1403 8-749-923-05 IC TORX178B (DIGITAL MD/TAPE OPTICAL IN
(DB870), MD/DAT OPTICAL IN (DB1070))
IC1404 8-749-923-04 IC TOTX178A (DIGITAL MD/TAPE OPTICAL
OUT (DB870), MD/DAT OPTICAL OUT
(DB1070))
IC1405 8-759-242-70 IC TC7WU04F
IC1406 8-759-926-17 IC SN74HC153ANS
IC1407 8-759-546-74 IC TC7WH157FU (TE12R)
IC1408 8-759-825-15 IC LC89056W-E
IC1409 8-759-447-77 IC TC7WH74FU (TE12R)
IC1410 8-759-242-70 IC TC7WU04F
IC1501 8-759-698-76 IC CXD9617R
IC1502 8-759-538-16 IC IDT71V016S15PH-AUTL
IC1601 8-759-698-77 IC CXD9616R
IC1602 8-759-538-16 IC IDT71V016S15PH-AUTL
IC1701 8-759-641-86 IC BR24C16F-E2
IC1702 8-759-714-20 IC S-80929ANMP-DDS-T2
IC1703 8-759-836-80 IC MB91154PMT2-G-102-E1
IC1801 8-759-231-53 IC TA7805S
IC1802 8-759-231-53 IC TA7805S
DIGITAL
