STR-DE585
7
MAIN board
1
CNP801
2
CNP802
5
screw
(BVTP3 x 8)
3
two screws
(BVTP3 x 6)
4
two screws
(BVTP3 x 6)
6
two screws
(BVTP3 x 8
)
2-6. MAIN BOARD
