Sony STR-DE585 - Connectors, Jacks, Coils, Transistors

40
STR-DE585
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C1611 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1612 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1613 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C1614 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C1615 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C1616 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C1617 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1618 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1619 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1620 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1626 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1627 1-126-964-11 ELECT 10uF 20% 50V
C1631 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1632 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1633 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(AEP,UK)
C1634 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1635 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1905 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1906 1-126-935-11 ELECT 470uF 20% 16V
C1908 1-126-935-11 ELECT 470uF 20% 16V
C1909 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1910 1-126-935-11 ELECT 470uF 20% 16V
C1911 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1912 1-126-935-11 ELECT 470uF 20% 16V
C1913 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1914 1-126-947-11 ELECT 47uF 20% 16V
C1915 1-126-947-11 ELECT 47uF 20% 16V
(AEP,UK)
C1916 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(AEP,UK)
< CONNECTOR >
CNP5 1-779-978-11 PIN, CONNECTOR 3P
CNP6 1-784-928-11 PIN, CONNECTOR 13P
CNS1 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P
CNS2 1-784-041-41 CONNECTOR, BOARD TO BOARD 9P
CNS3 1-784-923-11 PIN, CONNECTOR 7P
CNS4 1-569-312-11 SOCKET, CONNECTOR (L TYPE) 27P
CNS7 1-569-060-11 SOCKET, CONNECTOR 11P (Canadian)
CNS7 1-569-321-11 SOCKET, CONNECTOR 15P (AEP,UK)
CNS8 1-569-315-11 SOCKET, CONNECTOR 5P
< DIODE >
D1001 8-719-016-74 DIODE 1SS352
D1101 8-719-016-74 DIODE 1SS352
D1501 8-719-049-09 DIODE 1SS367-T3SONY
D1502 8-719-049-09 DIODE 1SS367-T3SONY
D1601 8-719-016-74 DIODE 1SS352
D1905 8-719-053-18 DIODE 1SR154-400TE-25
D1906 8-719-053-18 DIODE 1SR154-400TE-25
D1907 8-719-053-18 DIODE 1SR154-400TE-25
< FERRITE BEAD >
FB1101 1-414-813-11 FERRITE, EMI (SMD)
FB1102 1-414-813-11 FERRITE, EMI (SMD)
FB1104 1-469-152-11 FERRITE, EMI (SMD)
FB1105 1-469-152-11 FERRITE, EMI (SMD)
FB1201 1-414-813-11 FERRITE, EMI (SMD)
FB1202 1-414-813-11 FERRITE, EMI (SMD)
FB1203 1-469-152-11 FERRITE, EMI (SMD)
FB1204 1-469-152-11 FERRITE, EMI (SMD)
FB1501 1-414-813-11 FERRITE, EMI (SMD)
FB1502 1-414-813-11 FERRITE, EMI (SMD)
FB1601 1-414-813-11 FERRITE, EMI (SMD)
FB1602 1-216-864-11 METAL CHIP 0 5% 1/10W
FB1603 1-216-864-11 METAL CHIP 0 5% 1/10W
< IC >
IC1101 8-759-825-15 IC LC89056W-E
IC1102 8-759-242-70 IC TC7WU04F
IC1105 6-600-014-01 IC TORX141L (DIGITAL OPTICAL VIDEO 2 IN)
IC1201 8-759-698-76 IC CXD9617R
IC1202 6-700-983-01 IC IS61LV6416-15T(ICSI)
IC1501 8-759-657-47 IC AK4527
IC1502 8-759-710-97 IC NJM4565M-D
IC1503 8-759-231-53 IC TA7805S
IC1552 8-759-710-97 IC NJM4565M-D
IC1601 6-801-261-01 IC MB90478PF-G-120-BND
IC1602 8-759-714-20 IC S-80929ANMP-DDS-T2
IC1604 8-759-641-86 IC BR24C16F-E2
IC1901 6-701-887-01 IC SI-3001KWF
IC1902 8-759-231-57 IC TA7810S
IC1903 8-759-647-11 IC uPC2905HF
IC1904 8-759-647-10 IC uPC2933HF
IC1905 8-759-647-10 IC uPC2933HF (AEP,UK)
< JACK >
J1101 1-794-972-11 JACK, PIN 1P (DIGITAL COAXIAL DVD/LD IN)
< JUMPER RESISTOR >
JR1103 1-216-864-11 METAL CHIP 0 5% 1/10W
JR1104 1-216-864-11 METAL CHIP 0 5% 1/10W
JR1111 1-216-864-11 METAL CHIP 0 5% 1/10W
JR1112 1-216-864-11 METAL CHIP 0 5% 1/10W
(Canadian)
JR1113 1-216-864-11 METAL CHIP 0 5% 1/10W
(Canadian)
JR1114 1-216-864-11 METAL CHIP 0 5% 1/10W
(Canadian)
JR1115 1-216-864-11 METAL CHIP 0 5% 1/10W
JR1116 1-216-864-11 METAL CHIP 0 5% 1/10W
JR1118 1-211-950-11 SHORT 0
JR1121 1-216-864-11 METAL CHIP 0 5% 1/10W
JR1122 1-216-864-11 METAL CHIP 0 5% 1/10W
JR1200 1-216-864-11 METAL CHIP 0 5% 1/10W
JR1210 1-211-950-11 SHORT 0
L1901 1-216-864-11 METAL CHIP 0 5% 1/10W
< TRANSISTOR >
Q1601 8-729-027-43 TRANSISTOR DTC114EKA-T146
DIGITAL
