Sony STR-DE585 - Diodes, ICs, Coils, Transistors, Switches

43
STR-DE585
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< DIODE >
D100 8-719-075-59 LED SELS5B23C-TP15 (Digital Cinema Sound)
D102 8-719-084-07 LED SEL5E20C-TP15
(MULTI CHANNEL DECODING)
D103 8-719-046-39 LED SEL5821A-TP15 (SOUND FIELD A.DEC)
D104 8-719-046-39 LED SEL5821A-TP15 (SOUND FIELD 2CH)
D105 8-719-046-39 LED SEL5821A-TP15 (SOUND FIELD MODE)
D111 8-719-046-39 LED SEL5821A-TP15
(SOUND CONTROL LEVEL)
D112 8-719-046-39 LED SEL5821A-TP15 (SOUND CONTROL SURR)
D113 8-719-046-39 LED SEL5821A-TP15 (SET UP)
D114 8-719-046-39 LED SEL5821A-TP15 (NAME)
< FLUORESCENT INDICATOR >
FL101 1-518-718-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC100 8-759-643-83 IC uPD16315GB-3BS
IC101 8-759-036-90 IC MC74ACT08N
IC102 6-600-055-01 IC GP1UD27SXK
< COIL >
L101 1-412-473-21 INDUCTOR (SMALL TYPE)
L102 1-408-088-00 INDUCTOR 220uH
< TRANSISTOR >
Q100 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q101 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q102 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q103 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q104 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q107 8-729-900-36 TRANSISTOR DTC124ES
Q108 8-729-900-36 TRANSISTOR DTC124ES
Q109 8-729-900-36 TRANSISTOR DTC124ES
Q110 8-729-900-63 TRANSISTOR DTA124ES
Q111 8-729-900-63 TRANSISTOR DTA124ES
< RESISTOR >
R101 1-249-413-11 CARBON 470 5% 1/4W
R102 1-249-417-11 CARBON 1K 5% 1/4W
R103 1-249-417-11 CARBON 1K 5% 1/4W
R104 1-249-421-11 CARBON 2.2K 5% 1/4W
R105 1-249-421-11 CARBON 2.2K 5% 1/4W
R106 1-249-425-11 CARBON 4.7K 5% 1/4W
R107 1-249-429-11 CARBON 10K 5% 1/4W
R108 1-249-433-11 CARBON 22K 5% 1/4W
R109 1-249-437-11 CARBON 47K 5% 1/4W
R111 1-249-413-11 CARBON 470 5% 1/4W
R112 1-249-417-11 CARBON 1K 5% 1/4W
R113 1-249-417-11 CARBON 1K 5% 1/4W
R114 1-249-421-11 CARBON 2.2K 5% 1/4W
R115 1-249-421-11 CARBON 2.2K 5% 1/4W
R116 1-249-425-11 CARBON 4.7K 5% 1/4W
R117 1-249-429-11 CARBON 10K 5% 1/4W
R118 1-249-433-11 CARBON 22K 5% 1/4W
R119 1-249-437-11 CARBON 47K 5% 1/4W
R121 1-249-413-11 CARBON 470 5% 1/4W
R122 1-249-417-11 CARBON 1K 5% 1/4W
R123 1-249-417-11 CARBON 1K 5% 1/4W
R124 1-249-421-11 CARBON 2.2K 5% 1/4W
R125 1-249-421-11 CARBON 2.2K 5% 1/4W
R126 1-249-425-11 CARBON 4.7K 5% 1/4W
R127 1-249-429-11 CARBON 10K 5% 1/4W
R128 1-249-433-11 CARBON 22K 5% 1/4W
R131 1-249-413-11 CARBON 470 5% 1/4W
R132 1-249-417-11 CARBON 1K 5% 1/4W
R133 1-249-417-11 CARBON 1K 5% 1/4W
R134 1-249-421-11 CARBON 2.2K 5% 1/4W
R135 1-249-421-11 CARBON 2.2K 5% 1/4W
R136 1-249-425-11 CARBON 4.7K 5% 1/4W
R137 1-249-429-11 CARBON 10K 5% 1/4W
R141 1-249-421-11 CARBON 2.2K 5% 1/4W
R142 1-249-421-11 CARBON 2.2K 5% 1/4W
R143 1-249-421-11 CARBON 2.2K 5% 1/4W
R144 1-249-421-11 CARBON 2.2K 5% 1/4W
R148 1-249-421-11 CARBON 2.2K 5% 1/4W
R150 1-249-440-11 CARBON 82K 5% 1/4W
R153 1-247-807-31 CARBON 100 5% 1/4W
R154 1-249-393-11 CARBON 10 5% 1/4W
R155 1-249-441-11 CARBON 100K 5% 1/4W
R160 1-247-807-31 CARBON 100 5% 1/4W
R161 1-247-807-31 CARBON 100 5% 1/4W
R162 1-247-807-31 CARBON 100 5% 1/4W
R163 1-247-807-31 CARBON 100 5% 1/4W
R164 1-249-429-11 CARBON 10K 5% 1/4W
R165 1-249-403-11 CARBON 68 5% 1/4W
R166 1-249-409-11 CARBON 220 5% 1/4W
R167 1-249-409-11 CARBON 220 5% 1/4W
R168 1-249-409-11 CARBON 220 5% 1/4W
R169 1-249-409-11 CARBON 220 5% 1/4W
R170 1-249-429-11 CARBON 10K 5% 1/4W
R171 1-249-429-11 CARBON 10K 5% 1/4W
R175 1-249-393-11 CARBON 10 5% 1/4W
R198 1-249-381-11 CARBON 1 5% 1/4W
R199 1-249-381-11 CARBON 1 5% 1/4W
< ROTARY ENCODER >
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (PRESET TUNING –)
(Canadian)
S100 1-771-410-21 SWITCH, TACTILE (PRESET/PTY SELECT –)
(AEP,UK)
S101 1-771-410-21 SWITCH, TACTILE (TUNING –)
S102 1-771-410-21 SWITCH, TACTILE (NAME)
S103 1-771-410-21 SWITCH, TACTILE (ENTER)
S104 1-771-410-21 SWITCH, TACTILE (SOUND CONTROL LEVEL)
S105 1-771-410-21 SWITCH, TACTILE (SOUND CONTROL SURR)
S106 1-786-348-21 SWITCH, KEYBOARD (MENU –)
DISPLAY
