Sony STR-DE585 - Main Board Diodes, ICs, Jacks, Coils, Transistors

46
STR-DE585
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CC08 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP,UK)
CC09 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP,UK)
CC12 1-127-876-21 CERAMIC 0.01uF 10% 50V
(AEP,UK)
CC14 1-127-876-21 CERAMIC 0.01uF 10% 50V
(AEP,UK)
CC16 1-127-876-21 CERAMIC 0.01uF 10% 50V
(AEP,UK)
CC18 1-127-876-21 CERAMIC 0.01uF 10% 50V
(AEP,UK)
CC20 1-127-876-21 CERAMIC 0.01uF 10% 50V
(AEP,UK)
CC31 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP,UK)
CC32 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP,UK)
CC41 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP,UK)
CC42 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP,UK)
CC52 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP,UK)
CC54 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP,UK)
CC55 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP,UK)
CC56 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP,UK)
CC57 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP,UK)
CC58 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP,UK)
CC59 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP,UK)
CC61 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP,UK)
CC62 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP,UK)
< CONNECTOR >
CNP501 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
CNP502 1-784-038-21 CONNECTOR, BOARD TO BOARD 9P
* CNP801 1-564-104-00 PIN, CONNECTOR (B3P-VH) 3P
CNP802 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CNP911 1-784-928-11 PIN, CONNECTOR 13P
CNP915 1-766-200-11 SOCKET, CONNECTOR PIN 5P
< DIODE >
D505 8-719-991-33 DIODE 1SS133T-77
D510 8-719-991-33 DIODE 1SS133T-77
D540 8-719-991-33 DIODE 1SS133T-77
D560 8-719-991-33 DIODE 1SS133T-77
D605 8-719-991-33 DIODE 1SS133T-77
D610 8-719-991-33 DIODE 1SS133T-77
D640 8-719-991-33 DIODE 1SS133T-77
D665 8-719-991-33 DIODE 1SS133T-77
D680 8-719-991-33 DIODE 1SS133T-77
D690 8-719-934-21 DIODE HZS30-1L
D691 8-719-991-33 DIODE 1SS133T-77
D705 8-719-991-33 DIODE 1SS133T-77
D710 8-719-991-33 DIODE 1SS133T-77
D721 8-719-991-33 DIODE 1SS133T-77
D722 8-719-991-33 DIODE 1SS133T-77
D731 8-719-991-33 DIODE 1SS133T-77
D732 8-719-991-33 DIODE 1SS133T-77
D733 8-719-991-33 DIODE 1SS133T-77
D734 8-719-991-33 DIODE 1SS133T-77
D740 8-719-991-33 DIODE 1SS133T-77
D750 8-719-991-33 DIODE 1SS133T-77
D765 8-719-991-33 DIODE 1SS133T-77
D791 8-719-991-33 DIODE 1SS133T-77
D801 8-719-934-21 DIODE HZS30-1L
D802 8-719-072-05 DIODE RBV-602LF-A
D804 8-719-118-63 DIODE RD5.6F-T7B2
D896 8-719-043-76 DIODE AK04V0
D902 8-719-200-82 DIODE 11ES2
D903 8-719-200-82 DIODE 11ES2
D904 8-719-200-82 DIODE 11ES2
D905 8-719-200-82 DIODE 11ES2
< IC >
IC201 6-701-567-01 IC M61511FP-R61G
IC401 8-759-636-74 IC M5218AP-22
IC501 8-749-011-16 IC STK350-230
IC601 8-759-636-74 IC M5218AP-22
IC701 6-700-943-01 IC uPC2581V-S
IC702 6-700-943-01 IC uPC2581V-S
IC801 8-759-649-68 IC uPC78M07AHF
IC802 8-759-604-95 IC M5F79M07L
< JACK >
J401 1-774-411-11 JACK, PIN 6P (MULTI CH IN FRONT/
SURROUND/CENTER/SUB WOOFER)
J402 1-770-614-11 JACK, PIN 4P (CD IN,MD/TAPE OUT)
J403 1-770-614-11 JACK, PIN 4P (MD/TAPE IN,DVD/LD AUDIO IN)
J404 1-774-411-11 JACK, PIN 6P (VIDEO 2 AUDIO IN,
VIDEO 1 AUDIO OUT/AUDIO IN)
J405 1-774-843-11 JACK, PIN 1P (SUB WOOFER AUDIO OUT)
< COIL >
L521 1-422-009-13 COIL, AIR-CORE
L601 1-422-009-13 COIL, AIR-CORE
L651 1-422-009-13 COIL, AIR-CORE
L701 1-422-009-13 COIL, AIR-CORE
L751 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q361 8-729-823-22 TRANSISTOR 2SC3576
Q362 8-729-823-22 TRANSISTOR 2SC3576
Q363 8-729-823-22 TRANSISTOR 2SC3576
Q364 8-729-823-22 TRANSISTOR 2SC3576
Q365 8-729-823-22 TRANSISTOR 2SC3576
Q366 8-729-823-22 TRANSISTOR 2SC3576
MAIN
