Menu list (on the display panel)
The following options are available in each menu.
Auto Calibration settings [<AUTO CAL>]
Auto Calibration start [A.CAL START]
Auto Calibration type [CAL TYPE] (*1)
FULL FLAT, ENGINEER, FRONT REF, OFF
Automatic Phase Matching [A.P.M.] (*1)
A.P.M. AUTO, A.P.M. OFF
Level settings [<LEVEL>]
Test Tone [TEST TONE] (*2)
OFF, AUTO XXX (*3), FIX XXX (*3)
Test Tone Phase Noise [P. NOISE] (*2)
OFF, FL/FR, FL/CNT, CNT/FR, FR/SR, SR/SBR, SR/SB, SBR/SBL, SR/SL, SBL/SL,
SB/SL, SL/FL, LH/RH, FL/SR, SL/FR, FL/RH, LH/FR
Test Tone Phase Audio [P. AUDIO] (*2)
OFF, FL/FR, FL/CNT, CNT/FR, FR/SR, SR/SBR, SR/SB, SBR/SBL, SR/SL, SBL/SL,
SB/SL, SL/FL, LH/RH, FL/SR, SL/FR, FL/RH, LH/FR
Front left speaker level [FL LEVEL] (*2)
FL -10.0 dB to FL +10.0 dB (0.5 dB interval)
Front right speaker level [FR LEVEL] (*2)
FR -10.0 dB to FR +10.0 dB (0.5 dB interval)
Center speaker level [CNT LEVEL] (*2)
CNT -10.0 dB to CNT +10.0 dB (0.5 dB interval)
Surround left speaker level [SL LEVEL] (*2)
SL -10.0 dB to SL +10.0 dB (0.5 dB interval)
Surround right speaker level [SR LEVEL] (*2)
SR -10.0 dB to SR +10.0 dB (0.5 dB interval)
Surround back speaker level [SB LEVEL] (*2)
SB -10.0 dB to SB +10.0 dB (0.5 dB interval)
Surround back left speaker level [SBL LEVEL] (*2)
SBL -10.0 dB to SBL +10.0 dB (0.5 dB interval)
Surround back right speaker level [SBR LEVEL] (*2)
SBR -10.0 dB to SBR +10.0 dB (0.5 dB interval)
Front left high speaker level [LH LEVEL] (*2)
LH -10.0 dB to LH +10.0 dB (0.5 dB interval)
Front right high speaker level [RH LEVEL] (*2)
