56
STR-K980
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R758 1-249-431-11 CARBON 15K 5% 1/4W
R759 1-247-879-91 CARBON 100K 5% 1/4W
R760 1-249-421-11 CARBON 2.2K 5% 1/4W
R761 1-249-440-11 CARBON 82K 5% 1/4W
R763 1-249-414-11 CARBON 560 5% 1/4W
0 R764 1-249-399-11 CARBON 33 5% 1/4W
0 R765 1-249-399-11 CARBON 33 5% 1/4W
0 R766 1-234-182-11 ENCAPSULATED COMPONENT
0 R767 1-249-393-11 CARBON 10 5% 1/4W
0 R768 1-249-389-11 CARBON 4.7 5% 1/4W
R769 1-247-847-91 CARBON 4.7K 5% 1/4W
0 R771 1-240-855-81 CARBON 6.2K 5% 1/4W
R772 1-249-419-11 CARBON 1.5K 5% 1/4W
R773 1-247-871-91 CARBON 47K 5% 1/4W
R775 1-249-439-11 CARBON 68K 5% 1/4W
R778 1-249-431-11 CARBON 15K 5% 1/4W
R780 1-249-429-11 CARBON 10K 5% 1/4W
R791 1-249-421-11 CARBON 2.2K 5% 1/4W
R792 1-215-868-00 METAL OXIDE 680 5% 1W
0 R793 1-249-404-00 CARBON 82 5% 1/4W
R794 1-215-868-00 METAL OXIDE 680 5% 1W
0 R802 1-249-409-11 CARBON 220 5% 1/4W
0 R803 1-249-389-11 CARBON 4.7 5% 1/4W
R804 1-249-429-11 CARBON 10K 5% 1/4W
R806 1-247-863-91 CARBON 22K 5% 1/4W
R843 1-247-831-91 CARBON 1K 5% 1/4W
R844 1-247-863-91 CARBON 22K 5% 1/4W
0 R910 1-240-877-11 FUSIBLE 0.15 5% 1/2W
R3001 1-247-863-91 CARBON 22K 5% 1/4W
R3002 1-247-863-91 CARBON 22K 5% 1/4W
R3003 1-247-863-91 CARBON 22K 5% 1/4W
R3005 1-249-421-11 CARBON 2.2K 5% 1/4W
R3006 1-249-429-11 CARBON 10K 5% 1/4W
R3007 1-249-414-11 CARBON 560 5% 1/4W
0 R3008 1-249-393-11 CARBON 10 5% 1/4W
< RELAY >
RY560 1-755-267-11 RELAY
RY601 1-755-170-11 RELAY (12V)
RY701 1-755-170-11 RELAY (12V)
RY791 1-755-170-11 RELAY (12V)
< TERMINAL >
TM601 1-780-364-11 TERMINAL BOARD (SP) (8P)
(SURROUND, FRONT/SPEAKERS IMPEDANCE 6-16Ω)
*************************************************************
POWER BOARD
*************
< RESISTOR >
R114 1-247-831-91 CARBON 1K 5% 1/4W
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (?/1)
S115 1-771-410-21 SWITCH, TACTILE (SPEAKERS ON/OFF)
*************************************************************
SPEAKER C/SB BOARD
*******************
< CAPACTOR >
CC16 1-127-876-11 CERAMIC 0.01uF 10% 50V
CC17 1-127-876-11 CERAMIC 0.01uF 10% 50V
< CONNECTOR >
* CNP503 1-564-241-11 PIN, CONNECTOR (3.96mm PITCH) 4P
< DIODE >
D510 8-719-991-33 DIODE 1SS133T-72
< COIL >
L571 1-420-872-52 COIL, AIR-CORE
L751 1-420-872-52 COIL, AIR-CORE
< TRANSISTOR >
Q550 8-729-119-78 TRANSISTOR 2SC1740S-QRT
< RESISTOR >
R531 1-249-421-11 CARBON 2.2K 5% 1/4W
0 R534 1-249-404-00 CARBON 82 5% 1/4W
0 R578 1-249-389-11 CARBON 4.7 5% 1/4W
0 R751 1-249-389-11 CARBON 4.7 5% 1/4W
0 RR16 1-249-393-11 CARBON 10 5% 1/4W
0 RR17 1-249-393-11 CARBON 10 5% 1/4W
< RELAY >
RY501 1-755-170-11 RELAY (12V)
< TERMINAL >
TM502 1-780-217-11 TERMINAL BOARD (SP) (2P) (CENTER)
*************************************************************
SPEAKER B BOARD
****************
< CONNECTOR >
* CNP807 1-564-242-00 PIN, CONNECTOR (3.96mm PITCH) 5P
*************************************************************
STANDBY BOARD
**************
< CAPACITOR >
C913 1-127-888-11 CERAMIC 0.1uF 10% 50V
C914 1-127-888-11 CERAMIC 0.1uF 10% 50V
C915 1-126-943-11 ELECT 2200uF 20% 25V
C916 1-126-942-61 ELECT 1000uF 20% 25V
C920 1-127-888-11 CERAMIC 0.1uF 10% 50V
C921 1-127-888-11 CERAMIC 0.1uF 10% 50V
C924 1-126-960-11 ELECT 1uF 20% 50V
C950 1-126-936-11 ELECT 3300uF 20% 16V
POWERMAIN SPEAKER C/SB SPEAKER B STANDBY
