57
STR-K980
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< CONNECTOR >
CNP801 1-784-922-11 PIN, CONNECTOR 5P
CNP804 1-564-506-11 PLUG, CONNECTOR 3P
CNP901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CNP902 1-794-577-21 PIN, CONNECTOR (POWER)
CNP903 1-779-977-11 PIN, CONNECTOR 6P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-72
D910 6-500-522-11 DIODE 10EDB40-TA2B5
D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 6-500-522-11 DIODE 10EDB40-TA2B5
D913 6-500-522-11 DIODE 10EDB40-TA2B5
D914 8-719-991-33 DIODE 1SS133T-72
D915 8-719-991-33 DIODE 1SS133T-72
D920 6-500-522-11 DIODE 10EDB40-TA2B5
D921 6-500-522-11 DIODE 10EDB40-TA2B5
D922 6-500-522-11 DIODE 10EDB40-TA2B5
D923 6-500-522-11 DIODE 10EDB40-TA2B5
< FUSE HOLDER >
FH901 1-533-217-41 HOLDER, FUSE
FH951 1-533-217-41 HOLDER, FUSE
< GROUND TERMINAL >
G901 1-537-738-21 TERMINAL, GROUND
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q921 8-729-119-78 TRANSISTOR 2SC1740S-QRT
< RESISTOR >
0 R810 1-243-634-91 FUSIBLE 0.22 5% 1/2W
0 R811 1-243-634-91 FUSIBLE 0.22 5% 1/2W
R902 1-247-871-91 CARBON 47K 5% 1/4W
R903 1-249-421-11 CARBON 2.2K 5% 1/4W
0 R904 1-249-381-11 CARBON 1 5% 1/4W
R921 1-247-871-91 CARBON 47K 5% 1/4W
R922 1-247-863-91 CARBON 22K 5% 1/4W
R923 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0 RY901 1-755-541-11 RELAY
< TRANSFORMER >
0 T902 1-443-518-11 POWER TRANSFORMER
*************************************************************
VIDEO BOARD
***********
< CAPACITOR >
C200 1-128-805-11 CERAMIC 47PF 5% 50V
C201 1-128-805-11 CERAMIC 47PF 5% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-126-964-11 ELECT 10uF 20% 50V
C214 1-127-888-11 CERAMIC 0.1uF 10% 50V
C215 1-127-888-11 CERAMIC 0.1uF 10% 50V
C220 1-126-947-11 ELECT 47uF 20% 35V
C221 1-126-934-11 ELECT 220uF 20% 16V
C223 1-127-888-11 CERAMIC 0.1uF 10% 50V
C224 1-127-888-11 CERAMIC 0.1uF 10% 50V
C308 1-126-964-11 ELECT 10uF 20% 50V
C309 1-126-964-11 ELECT 10uF 20% 50V
C310 1-126-964-11 ELECT 10uF 20% 50V
C311 1-126-964-11 ELECT 10uF 20% 50V
C312 1-126-964-11 ELECT 10uF 20% 50V
C313 1-126-964-11 ELECT 10uF 20% 50V
C315 1-127-868-11 CERAMIC 2200PF 10% 50V
C316 1-127-868-11 CERAMIC 2200PF 10% 50V
C330 1-127-888-11 CERAMIC 0.1uF 10% 50V
C331 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CNP202 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CNP203 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CNS203 1-784-778-11 CONNECTOR, FFC 17P
< DIODE >
D203 8-719-991-33 DIODE 1SS133T-72
D204 8-719-991-33 DIODE 1SS133T-72
< IC >
IC203 6-701-890-01 IC NJM2595D
IC304 6-707-363-01 IC NJM2586AL
IC804 8-759-245-79 IC TA79005S
IC807 8-759-231-53 IC TA7805S
< JACK >
J200 1-794-978-11 JACK, PIN 3P
(DVD/VIDEO IN, VIDEO 2/VIDEO IN, VIDEO 1/VIDEO OUT)
J201 1-815-043-11 JACK, PIN 2P
(VIDEO 1/VIDEO IN, MONITOR/VIDEO OUT)
J301 1-816-592-11 JACK, PIN 9P
(COMPONENT VIDEO/MONITOR OUT, VIDEO2 IN, DVD IN)
< RESISTOR >
R200 1-247-804-11 CARBON 75 5% 1/4W
R201 1-247-804-11 CARBON 75 5% 1/4W
R218 1-247-804-11 CARBON 75 5% 1/4W
R219 1-247-804-11 CARBON 75 5% 1/4W
R220 1-247-804-11 CARBON 75 5% 1/4W
R221 1-247-804-11 CARBON 75 5% 1/4W
R301 1-247-804-11 CARBON 75 5% 1/4W
R302 1-247-804-11 CARBON 75 5% 1/4W
R303 1-247-804-11 CARBON 75 5% 1/4W
R304 1-247-804-11 CARBON 75 5% 1/4W
R305 1-247-804-11 CARBON 75 5% 1/4W
R306 1-247-804-11 CARBON 75 5% 1/4W
R307 1-247-804-11 CARBON 75 5% 1/4W
R308 1-247-804-11 CARBON 75 5% 1/4W
R309 1-247-804-11 CARBON 75 5% 1/4W
