58
STR-K980
Ref. No. Part No. Description Remark
R310 1-247-831-91 CARBON 1K 5% 1/4W
R311 1-247-831-91 CARBON 1K 5% 1/4W
R312 1-247-831-91 CARBON 1K 5% 1/4W
R313 1-247-863-91 CARBON 22K 5% 1/4W
*************************************************************
VIDEO 3 BOARD
*************
< CAPACITOR >
C293 1-127-888-11 CERAMIC 0.1uF 10% 50V
C294 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CN201 1-784-922-11 PIN, CONNECTOR 5P
< JACK >
J298 1-819-187-11 PIN JACK 3P
(VIDEO, AUDIO//VIDEO 3 IN/PORTABLE AV IN)
< RESISTOR >
R298 1-247-831-91 CARBON 1K 5% 1/4W
R299 1-247-831-91 CARBON 1K 5% 1/4W
< FLAT CABLE >
* W290 1-690-880-31 LEAD (WITH CONNECTOR)
*************************************************************
MISCELANIOUS
*************
8 1-829-023-11 WIRE (FLAT TYPE) (23 CORE)
0 57 1-829-627-11 POWER-SUPPLY CORD
59 1-828-993-11 WIRE (FLAT TYPE) (17 CORE)
60 1-828-963-11 WIRE (FLAT TYPE) (11 CORE)
0 F901 1-532-350-00 FUSE (T4AL/250V)
Q503 6-702-390-01 IC MN2488-OPY-MK
Q504 6-702-391-01 IC MP1620-OPY-MK
Q533 6-702-390-01 IC MN2488-OPY-MK
Q534 6-702-391-01 IC MP1620-OPY-MK
Q653 6-702-390-01 IC MN2488-OPY-MK
Q654 6-702-391-01 IC MP1620-OPY-MK
Q703 6-702-390-01 IC MN2488-OPY-MK
Q704 6-702-391-01 IC MP1620-OPY-MK
Q753 6-702-390-01 IC MN2488-OPY-MK
Q754 6-702-391-01 IC MP1620-OPY-MK
0 T901 1-443-523-11 POWER TRANSFORMER
TN1 1-693-675-11 TUNER
