Sony STR-KM5000 - Page 47

STR-KM5000
47
Pin No. Pin Name I/O Description
58 POWER_RY O Relay drive signal (for main power) output terminal "H": relay on
59 TUNING_A I Jog dial pulse input from the rotary encoder (for - TUNING +) (A phase input)
60 TUNING_B I Jog dial pulse input from the rotary encoder (for - TUNING +) (B phase input)
61 PROTECTOR I Protector status detect signal input terminal
62 HP_RY O Relay drive signal (for headphone) output terminal "H": relay on
63 FUSE_DETECT I Fuse detection signal input terminal
64 VOL_ENCODER(B) I Jog dial pulse input from the rotary encoder (for MASTER VOLUME) (B phase input)
65 VOL_ENCODER(A) I Jog dial pulse input from the rotary encoder (for MASTER VOLUME) (A phase input)
66 C/SW/REAR/SB_RY O Relay drive signal (for center, surround, surround back) output terminal "H": relay on
67
FRONT B RY/
ST SW RY
O Relay drive signal (for front B) output terminal "H": relay on
68 DC-CONTROL - Not used
69 SW_RY O Relay drive signal (for subwoofer) output terminal "H": relay on
70 FRONT A RY O Relay drive signal (for front A) output terminal "H": relay on
71 to 73 NC - Not used
74 FL_CLK O Serial data transfer clock signal output to the fl uorescent indicator tube
75 FL_DATA O Serial data output to the fl uorescent indicator tube
76 FL_LAT O Strobe signal output to the fl uorescent indicator tube
77 RSTX I Reset signal input from the reset signal buffer
78 NC - Not used
79 X0A I Sub system clock input terminal Not used
80 X1A O Sub system clock output terminal Not used
81 VSS - Ground terminal
82 X0 I Main system clock input terminal (24 MHz)
83 X1 O Main system clock output terminal (24 MHz)
84 VCC3 - Power supply terminal (+3.3V)
85 +5.8V_CTRL(HDMI) - Not used
86 RESET_HDMI O System reset signal output to the HDMI reciever/transciever
87 +V_CTRL(HDMI) O HDMI control signal output to the HDMI reciever/transciever
88 HDMI_DET I Headphone detection signal input from the HDMI reciever/transciever
89 DO/SD/ST I PLL data input from the tuner (FM/AM)
90 TUNER_CLK O Serial data transfer clock signal output to the tuner (FM/AM)
91 TUNE_DATA O Serial data output to the tuner (FM/AM)
92 SLATCH O Serial data latch pulse signal output to the tuner (FM/AM)
93 DIR_XMODE O Reset signal output to the digital audio interface receiver "L": reset
94 DIR_CKSEL1 O Clock selection signal output to the digital audio interface receiver
95 DIR_CLK O Serial data transfer clock signal output to the digital audio interface receiver
96 DIR_CE O Chip enable signal output to the digital audio interface receiver
97 DIR_DI O Serial data output to the digital audio interface receiver
98 DIR_DO I Serial data input from the digital audio interface receiver
99 DIR_ERROR I PLL lock error signal and data error fl ag input from the digital audio interface receiver
100 DIR_XSTATE I Source clock selection monitor input from the digital audio interface receiver
