56
STR-KM5000
SECTION 8
ELECTRICAL PARTS LIST
AC SELECT BOARD (E51)
****************
< CONNECTOR >
CNP903 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P
* CNP905 1-564-687-11 PIN, CONNECTOR (3.96mm PITCH) 3P
< SWITCH >
S901 1-571-437-21 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR)
*************************************************************
DCAC BOARD
***********
< CAPACITOR >
C2001 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2002 1-126-160-11 ELECT 1uF 20% 50V
C2003 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C2005 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C2006 1-126-160-11 ELECT 1uF 20% 50V
C2008 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C2010 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C2011 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C2012 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C2013 1-126-160-11 ELECT 1uF 20% 50V
C2014 1-124-465-00 ELECT 0.47uF 20% 50V
C2018 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C2205 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< DIODE >
D2013 6-501-817-01 DIODE MA2J1110GLS0
D2014 6-501-817-01 DIODE MA2J1110GLS0
< IC >
IC2000 8-759-710-97 IC NJM4565M-D
< JACK >
J2000 1-820-056-21 SMALL TYPE JACK (3.5MM) (AUTO CAL MIC)
< RESISTOR >
R2000 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2001 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2003 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2005 1-216-857-11 METAL CHIP 1M 5% 1/10W
R2006 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2007 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2008 1-216-854-11 METAL CHIP 560K 5% 1/10W
R2010 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2015 1-216-839-11 METAL CHIP 33K 5% 1/10W
R2016 1-216-835-11 METAL CHIP 15K 5% 1/10W
R2017 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2018 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R2019 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< LEAD >
* TP2000 1-690-880-31 LEAD (WITH CONNECTOR)
*************************************************************
DCDC CONVERTER BOARD
**********************
< CAPACITOR >
C4002 1-128-549-11 ELECT 3300uF 20% 35V
C4003 1-128-959-21 ELECT 1000uF 20% 35V
C4004 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C4005 1-128-950-21 ELECT 1000uF 20% 16V
C4006 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C4011 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C4012 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
< CONNECTOR >
CN4001 1-778-226-21 CONNECTOR, BOARD TO BOARD 6P
< DIODE >
0 D4001 8-719-077-77 DIODE D3SB60F3
0 D4803 6-502-218-01 DIODE RB060M-30
< FUSE HOLDER >
FH4001 1-533-233-11 FUSE HOLDER
FH4002 1-533-233-11 FUSE HOLDER
FH4003 1-533-233-11 FUSE HOLDER
FH4004 1-533-233-11 FUSE HOLDER
< IC >
0 IC4001 8-759-474-09 IC SI-8050S-LF1101
< COIL >
L4000 1-456-545-11 COIL, CHOKE 100uH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DCDC CONVERTER
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
DCAC
AC SELECT
Ver. 1.1
• Abbreviation
AR : Argentina model
E51 : Chilean and Peruvian models
MX : Mexican model
MY : Malaysia model
SP : Singapore model
TH : Thai model
To Next Page
