Sony STR-KM5000 User Manual

STR-KM5000
5
About the indicators on the display
SW
LFE
LC
SL S

D EX

PLIIx

PL OPT DTS -ES 96/24 MEMORY ST
MONOD.RANGECOAXHDMI NEO:6
SB
R
SR
     
RRG RTRE RB
Name Function
" SW Lightsupwhentheaudiosignal
is output from the
SUBWOOFER jack.
# LFE Lights up when the disc being
played back contains an LFE
(Low Frequency Effect)
channel and the LFE channel
signal is actually being
reproduced.
$ D/
DEX
“D” lights up when Dolby
Digital signals are input.
“D EX” lights up when
Dolby Digital Surround EX
signals are decoded.
Note
When playing a Dolby Digital
format disc, be sure that you
have made digital connections
andthatINPUTMODEissetto
“AUTO”.
% PL/
PLII/
PLIIx
“PL” lights up when the
receiver applies Pro Logic
processing to 2 channel signals
inorderto outputthecenterand
surround channel signals.
“PLII” lights up when the
Pro Logic II Movie/Music/
Game decoder is activated.
“PLIIx” lights up when the
Pro Logic IIx Movie/Music/
Game decoder is activated.
Note
Dolby Pro Logic IIx decoding
does not function for DTS
format signals or for signals
with a sampling frequency of
more than 48 kHz.
Name Function
& OPT Lights upwhen INPUTMODE
issetto“AUTO”andthesource
signal is a digital signal being
input through the OPTICAL
jack.
' DTS/
DTS-ES/
DTS 96/24
“DTS” lights up when the
receiver is decoding DTS
signals.
“DTS-ES” lights up when the
receiver is decoding DTS-ES
signals.
“DTS96/24”lightsupwhenthe
receiver is decoding DTS 96
kHz/24 bit signals.
Note
When playing a DTS format
disc,besurethatyouhavemade
digital connections and that
INPUT MODE is set to
“AUTO”.
+ D.RANGE Lights up when dynamic range
compression is activated.
, NEO:6 Lights up when DTS Neo:6
Cinema/Music decoder is
activated.
- COAX Lights upwhen INPUTMODE
issetto“AUTO”andthesource
signal is a digital signal being
input through the COAXIAL
jack.
. HDMI Lights up when the receiver
recognizes a component
connectedviaanHDMIINjack.
/ Playback
channel
indicators
L
R
C
SL
SR
S
SB
The letters (L, C, R, etc.)
indicate the channels being
played back. The boxes around
theletters varytoshowhow the
receiver downmixes the source
sound.
Front Left
Front Right
Center (monaural)
Surround Left
Surround Right
Surround (monaural or the
surround components obtained
by Pro Logic processing)
Surround back (the surround
back components obtained by
6.1 channel decoding)
Example:
Recording format (Front/
Surround): 3/2.1
Sound Field: A.F.D. AUTO
SW
LC
SL
R
SR
( MEMORY Lights up when a memory
function, such as Preset
Memory, etc., is activated.
) Tuner
indicators
Lights up when using the
receivertotune inradiostations
, etc.
* Preset
station
indicators
Lights up when using the
receivertotune inradiostations
you have preset. For details on
presetting radio stations.
