10
CHASSIS (MOLD B) SECTION, STOCKER SECTION AND
SLIDER (SELECTION)
Note: In mounting the parts, refer to page 11 and 12.
GEARS INSTALLATION
5
stocker
section
4
two step
screws
4
two step screws
3
gear (eject)
2
chassis (mold B) section
Note: Rotating the pulley (LD),
shift the slider (selection
to the left.
9
compression
spring
7
slider (selection)
8
washer
6
two screws
(PTPWH M2.6)
1
three screws
(BVTP M2.6)
pulley (LD)
1
Slide the slider (U/D)
fully in the arrow
direction.
3
gear (gear B)
2
gear (U/D slider)
4
gear (gear A)
Adjust the gear (gear B) with the
portion A as shown.
Adjust the gear so that it meshes with
the bottom tooth of slider (U/D)gear,
as shown.
portion A
slider (U/D) gear
linearly
gear
(gear B)
Adjust so as to be aligned with
gear (B) linearly,as shown.
To Next Page
