Sony STR-NX3 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
36
C856 1-128-560-11 ELECT 22uF 20% 100V
C857 1-128-582-11 ELECT 10uF 20% 100V
C858 1-136-495-11 FILM 0.068uF 5% 50V
C859 1-136-495-11 FILM 0.068uF 5% 50V
C860 1-136-165-00 FILM 0.1uF 5% 50V
(AEP, UK)
C861 1-136-165-00 FILM 0.1uF 5% 50V
(AEP, UK)
C862 1-161-494-00 CERAMIC 0.022uF 25V
(AEP, UK)
C871 1-136-165-00 FILM 0.1uF 5% 50V
(NX3: AEP, UK)
C872 1-136-165-00 FILM 0.1uF 5% 50V
(NX3: AEP, UK)
C873 1-136-165-00 FILM 0.1uF 5% 50V
(NX3: AEP, UK)
C874 1-136-165-00 FILM 0.1uF 5% 50V
(NX3: AEP, UK)
C875 1-136-165-00 FILM 0.1uF 5% 50V
(NX3: AEP, UK)
C876 1-136-165-00 FILM 0.1uF 5% 50V
(NX3: AEP, UK)
C877 1-161-494-00 CERAMIC 0.022uF 25V
(NX3: AEP, UK)
C878 1-161-494-00 CERAMIC 0.022uF 25V
(NX3: AEP, UK)
C879 1-161-494-00 CERAMIC 0.022uF 25V
(NX3: AEP, UK)
C880 1-126-163-11 ELECT 4.7uF 20% 50V
C881 1-127-751-11 ELECT 3300uF 20% 50V
(NX3: US, CND, AEP, UK)
C881 1-127-811-11 ELECT 3300uF 20% 50V
(NX3: MY, SP, KR, AUS)
C882 1-127-751-11 ELECT 3300uF 20% 50V
(NX3: US, CND, AEP, UK)
C882 1-127-811-11 ELECT 3300uF 20% 50V
(NX3: MY, SP, KR, AUS)
C883 1-127-752-11 ELECT 3300uF 20% 63V
(AEP, UK)
C883 1-127-753-11 ELECT 3300uF 20% 71V
(US, CND)
C883 1-127-813-11 ELECT 3300uF 20% 71V
(E, AUS, JE)
C884 1-127-752-11 ELECT 3300uF 20% 63V
(AEP, UK)
C884 1-127-753-11 ELECT 3300uF 20% 71V
(US, CND)
C884 1-127-813-11 ELECT 3300uF 20% 71V
(E, AUS, JE)
C885 1-136-165-00 FILM 0.1uF 5% 50V
(NX3)
C886 1-136-165-00 FILM 0.1uF 5% 50V
(NX3)
C887 1-130-777-00 FILM 0.1uF 10% 100V
C888 1-130-777-00 FILM 0.1uF 10% 100V
C889 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN802 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
CN808 1-691-766-11 PLUG (MICRO CONNECTOR) 4P (NX1)
CN808 1-691-768-11 PLUG (MICRO CONNECTOR) 6P (NX3)
PA
< DIODE >
D802 8-719-911-19 DIODE 1SS133T-72
D821 8-719-911-19 DIODE 1SS133T-72
D831 8-719-911-19 DIODE 1SS133T-72
D852 8-719-911-19 DIODE 1SS133T-72
D871 8-719-911-19 DIODE 1SS133T-72
D881 8-719-510-68 DIODE D5SBA204101
D882 8-719-510-68 DIODE D5SBA204101 (NX3)
D883 8-719-911-19 DIODE 1SS133T-72
D884 8-719-911-19 DIODE 1SS133T-72 (NX3)
D885 8-719-911-19 DIODE 1SS133T-72 (NX3)
< GROUND TERMINAL >
EP802 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC801 8-749-015-39 IC STK407-120E
< COIL >
L801 1-420-872-00 COIL, AIR-CORE (AEP, UK)
L851 1-420-872-00 COIL, AIR-CORE (AEP, UK)
L871 1-420-872-00 COIL, AIR-CORE (NX3: AEP, UK)
L872 1-420-872-00 COIL, AIR-CORE (NX3: AEP, UK)
L873 1-420-872-00 COIL, AIR-CORE (NX3: AEP, UK)
< TRANSISTOR >
Q801 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q821 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q822 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q823 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q824 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q825 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q826 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q827 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q828 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q829 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q830 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q831 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q851 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q881 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q882 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q883 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA (NX3)
Q884 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA (NX3)
Q885 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA (NX3)
Q886 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA (NX3)
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W
R802 1-249-438-11 CARBON 56K 5% 1/4W
R803 1-249-414-11 CARBON 560 5% 1/4W
R804 1-249-438-11 CARBON 56K 5% 1/4W
0 R805 1-212-881-11 FUSIBLE 100 5% 1/4W F
0 R807 1-217-156-00 METAL 0.22 10% 5W F
R808 1-249-417-11 CARBON 1K 5% 1/4W
R809 1-249-431-11 CARBON 15K 5% 1/4W
R810 1-249-441-11 CARBON 100K 5% 1/4W
R811 1-260-076-11 CARBON 10 5% 1/2W
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
