Sony STR-NX3 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
37
R812 1-260-076-11 CARBON 10 5% 1/2W
(AEP, UK)
R813 1-260-076-11 CARBON 10 5% 1/2W
(AEP, UK)
R814 1-249-437-11 CARBON 47K 5% 1/4W
R821 1-249-435-11 CARBON 33K 5% 1/4W
R822 1-249-435-11 CARBON 33K 5% 1/4W
R823 1-249-439-11 CARBON 68K 5% 1/4W
R824 1-249-421-11 CARBON 2.2K 5% 1/4W
R825 1-249-433-11 CARBON 22K 5% 1/4W
R826 1-249-429-11 CARBON 10K 5% 1/4W
R827 1-249-433-11 CARBON 22K 5% 1/4W
0 R828 1-202-972-61 FUSIBLE 1 5% 1/4W F
R829 1-249-441-11 CARBON 100K 5% 1/4W
R830 1-249-441-11 CARBON 100K 5% 1/4W
R831 1-249-429-11 CARBON 10K 5% 1/4W
(NX1: AEP, UK)
R831 1-249-43‹-11 CARBON 12K 5% 1/4W
(US, CND/NX3: AEP, UK)
R831 1-249-432-11 CARBON 18K 5% 1/4W
(E, AUS, JE)
R832 1-249-431-11 CARBON 15K 5% 1/4W
R833 1-249-435-11 CARBON 33K 5% 1/4W
R836 1-249-425-11 CARBON 4.7K 5% 1/4W
R837 1-249-433-11 CARBON 22K 5% 1/4W
R838 1-249-435-11 CARBON 33K 5% 1/4W
R839 1-249-429-11 CARBON 10K 5% 1/4W
R840 1-249-429-11 CARBON 10K 5% 1/4W
R841 1-249-437-11 CARBON 47K 5% 1/4W
R842 1-249-438-11 CARBON 56K 5% 1/4W
R843 1-249-437-11 CARBON 47K 5% 1/4W
(NX3)
R844 1-249-437-11 CARBON 47K 5% 1/4W
(NX3)
R845 1-249-437-11 CARBON 47K 5% 1/4W
(NX3)
0 R850 1-202-972-61 FUSIBLE 1 5% 1/4W F
R851 1-249-417-11 CARBON 1K 5% 1/4W
R852 1-249-438-11 CARBON 56K 5% 1/4W
R853 1-249-414-11 CARBON 560 5% 1/4W
R854 1-249-438-11 CARBON 56K 5% 1/4W
0 R855 1-215-918-41 METAL OXIDE 1.5K 5% 3W F
0 R857 1-217-156-00 METAL 0.22 10% 5W F
R858 1-249-417-11 CARBON 1K 5% 1/4W
R859 1-249-431-11 CARBON 15K 5% 1/4W
R860 1-249-441-11 CARBON 100K 5% 1/4W
R861 1-260-076-11 CARBON 10 5% 1/2W
R862 1-260-076-11 CARBON 10 5% 1/2W
(AEP, UK)
R863 1-260-076-11 CARBON 10 5% 1/2W
(AEP, UK)
R864 1-249-437-11 CARBON 47K 5% 1/4W
R871 1-249-437-11 CARBON 47K 5% 1/4W
(NX3)
R872 1-249-437-11 CARBON 47K 5% 1/4W
(NX3)
R873 1-249-437-11 CARBON 47K 5% 1/4W
(NX3)
R874 1-260-076-11 CARBON 10 5% 1/2W
(NX3: AEP, UK)
R875 1-260-076-11 CARBON 10 5% 1/2W
(NX3: AEP, UK)
R876 1-260-076-11 CARBON 10 5% 1/2W
(NX3: AEP, UK)
R877 1-260-076-11 CARBON 10 5% 1/2W
(NX3: AEP, UK)
R878 1-260-076-11 CARBON 10 5% 1/2W
(NX3: AEP, UK)
R879 1-260-076-11 CARBON 10 5% 1/2W
(NX3: AEP, UK)
R881 1-249-429-11 CARBON 10K 5% 1/4W
R882 1-249-437-11 CARBON 47K 5% 1/4W
R883 1-249-429-11 CARBON 10K 5% 1/4W
R884 1-249-441-11 CARBON 100K 5% 1/4W
0 R885 1-216-481-41 METAL OXIDE 1.2K 5% 3W F
R886 1-249-429-11 CARBON 10K 5% 1/4W
(NX3)
R887 1-249-437-11 CARBON 47K 5% 1/4W
(NX3)
R888 1-249-429-11 CARBON 10K 5% 1/4W
(NX3)
R889 1-249-441-11 CARBON 100K 5% 1/4W
(NX3)
0 R890 1-215-918-41 METAL OXIDE 1.5K 5% 3W F
(NX3: E, AUS)
0 R890 1-216-481-41 METAL OXIDE 1.2K 5% 3W F
(NX3: US, CND, AEP, UK)
R891 1-249-429-11 CARBON 10K 5% 1/4W
(NX3)
R892 1-249-437-11 CARBON 47K 5% 1/4W
(NX3)
R893 1-249-429-11 CARBON 10K 5% 1/4W
(NX3)
R894 1-249-441-11 CARBON 100K 5% 1/4W
(NX3)
0 R895 1-215-918-41 METAL OXIDE 1.5K 5% 3W F
(NX3: E, AUS)
0 R895 1-216-481-41 METAL OXIDE 1.2K 5% 3W F
(NX3: US, CND, AEP, UK)
< RELAY >
RY881 1-755-168-11 RELAY
RY882 1-515-920-11 RELAY (24V) (NX3)
RY883 1-515-920-11 RELAY (24V) (NX3)
< TERMINAL >
TM801 1-537-240-11 TERMINAL BOARD (CHECKER PIN)
(FRONT SPEAKER)
TM802 1-537-240-11 TERMINAL BOARD (CHECKER PIN)
(REAR SPEAKER) (NX1)
TM802 1-537-510-11 TERMINAL BOARD (SPEAKER) (6P)
(REAR SPEAKER, CENTER SPEAKER) (NX3)
**************************************************************
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
