Sony STR-NX3 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
38
A-4426-226-A PANEL BOARD, COMPLETE
(NX1: US, CND, AEP, UK)
A-4426-249-A PANEL BOARD, COMPLETE (NX1: MY, SP, KR,
JE)
A-4426-258-A PANEL BOARD, COMPLETE
(NX3: US, CND, AEP, UK)
A-4426-275-A PANEL BOARD, COMPLETE (NX3: E, AUS)
A-4426-927-A PANEL BOARD, COMPLETE (NX1: TH)
**********************
< CAPACITOR >
C651 1-164-159-11 CERAMIC 0.1uF 50V
C652 1-104-664-11 ELECT 47uF 20% 16V
C653 1-162-306-11 CERAMIC 0.01uF 30% 16V
C654 1-162-306-11 CERAMIC 0.01uF 30% 16V
C655 1-162-306-11 CERAMIC 0.01uF 30% 16V
C656 1-162-306-11 CERAMIC 0.01uF 30% 16V
C657 1-104-664-11 ELECT 47uF 20% 16V
C658 1-104-664-11 ELECT 47uF 20% 16V
C659 1-104-664-11 ELECT 47uF 20% 16V
C660 1-164-159-11 CERAMIC 0.1uF 50V
C701 1-162-294-31 CERAMIC 0.001uF 10% 50V
C702 1-162-294-31 CERAMIC 0.001uF 10% 50V
C703 1-164-159-11 CERAMIC 0.1uF 50V
C706 1-126-961-11 ELECT 2.2uF 20% 50V
C707 1-162-306-11 CERAMIC 0.01uF 30% 16V
C708 1-162-294-31 CERAMIC 0.001uF 10% 50V
C709 1-162-215-31 CERAMIC 47PF 5% 50V
C710 1-162-290-31 CERAMIC 470PF 10% 50V
C711 1-104-664-11 ELECT 47uF 20% 16V
C712 1-126-956-91 ELECT 0.1uF 20% 50V
C713 1-162-215-31 CERAMIC 47PF 5% 50V
C714 1-162-282-31 CERAMIC 100PF 10% 50V
C716 1-104-664-11 ELECT 47uF 20% 16V
C717 1-126-961-11 ELECT 2.2uF 20% 50V
C741 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN601 1-784-731-11 CONNECTOR, FFC 9P
CN602 1-784-747-11 CONNECTOR, FFC 25P
CN603 1-568-850-11 CONNECTOR, FFC 7P
* CN606 1-560-666-00 PIN, CONNECTOR 3P
< LED >
D631 8-719-076-21 LED SEL5255S-TP15 (GROOVE)
D632 8-719-046-43 LED SEL5421E-TP15 (DVD 5.1CH) (NX3)
D633 8-719-046-43 LED SEL5421E-TP15 (PRO LOGIC) (NX3)
D636 8-719-076-21 LED SEL5255S-TP15 (ENTER)
D637 8-719-076-21 LED SEL5255S-TP15 (TIMER)
(US, CND, AEP, UK)
D638 8-719-076-21 LED SEL5255S-TP15 (?/1)
D643 8-719-076-15 LED SELS6B14C-TP6 (KEY ILLUMINATION)
D644 8-719-076-15 LED SELS6B14C-TP6 (KEY ILLUMINATION)
D645 8-719-076-15 LED SELS6B14C-TP6 (KEY ILLUMINATION)
D646 8-719-076-15 LED SELS6B14C-TP6 (KEY ILLUMINATION)
D647 8-719-076-15 LED SELS6B14C-TP6 (KEY ILLUMINATION)
D648 8-719-076-15 LED SELS6B14C-TP6 (KEY ILLUMINATION)
< GROUND TERMINAL >
EPT601 1-537-770-21 TERMINAL BOARD, GROUND
EPT602 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC701 8-759-634-51 IC M5218AP
< JACK >
J701 1-785-569-11 JACK (SMALL TYPE) (PHONES)
J702 1-785-569-11 JACK (SMALL TYPE) (MIC)
< COIL >
L601 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q631 8-729-900-36 TRANSISTOR BA1F4M-TP
Q632 8-729-900-36 TRANSISTOR BA1F4M-TP (NX3)
Q633 8-729-900-36 TRANSISTOR BA1F4M-TP (NX3)
Q636 8-729-900-36 TRANSISTOR BA1F4M-TP
Q637 8-729-900-36 TRANSISTOR BA1F4M-TP (US, CND, AEP,
UK)
Q638 8-729-900-36 TRANSISTOR BA1F4M-TP
Q641 8-729-900-36 TRANSISTOR BA1F4M-TP
Q642 8-729-900-36 TRANSISTOR BA1F4M-TP
Q643 8-729-900-36 TRANSISTOR BA1F4M-TP
< RESISTOR >
R602 1-249-411-11 CARBON 330 5% 1/4W
R603 1-249-413-11 CARBON 470 5% 1/4W
R604 1-249-414-11 CARBON 560 5% 1/4W
R605 1-249-415-11 CARBON 680 5% 1/4W
R606 1-249-417-11 CARBON 1K 5% 1/4W
R607 1-249-418-11 CARBON 1.2K 5% 1/4W
R608 1-249-420-11 CARBON 1.8K 5% 1/4W
R609 1-249-422-11 CARBON 2.7K 5% 1/4W
R610 1-247-843-11 CARBON 3.3K 5% 1/4W
R611 1-249-425-11 CARBON 4.7K 5% 1/4W
R612 1-249-427-11 CARBON 6.8K 5% 1/4W
R613 1-249-429-11 CARBON 10K 5% 1/4W
R614 1-249-431-11 CARBON 15K 5% 1/4W
R616 1-249-411-11 CARBON 330 5% 1/4W
R617 1-249-413-11 CARBON 470 5% 1/4W
R618 1-249-414-11 CARBON 560 5% 1/4W
R619 1-249-415-11 CARBON 680 5% 1/4W
R620 1-249-417-11 CARBON 1K 5% 1/4W
R621 1-249-418-11 CARBON 1.2K 5% 1/4W
R622 1-249-420-11 CARBON 1.8K 5% 1/4W
R623 1-249-422-11 CARBON 2.7K 5% 1/4W
(NX3)
R624 1-247-843-11 CARBON 3.3K 5% 1/4W
(NX3)
R626 1-249-410-11 CARBON 270 5% 1/4W
R627 1-249-410-11 CARBON 270 5% 1/4W
R631 1-249-411-11 CARBON 330 5% 1/4W
R632 1-249-411-11 CARBON 330 5% 1/4W
(NX3)
