Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 62 —
R742 1-249-439-11 CARBON 68K 5% 1/4W
(V7770)
R743 1-249-425-11 CARBON 4.7K 5% 1/4W
(V7770)
R744 1-249-437-11 CARBON 47K 5% 1/4W
(V7770)
! R745 1-216-457-00 METAL OXIDE 1.2K 5% 2W
(V7770)
R746 1-249-432-11 CARBON 18K 5% 1/4W
(V7770)
R747 1-249-437-11 CARBON 47K 5% 1/4W
(V7770)
R751 1-249-432-11 CARBON 18K 5% 1/4W
R752 1-249-439-11 CARBON 68K 5% 1/4W
R757 1-249-435-11 CARBON 33K 5% 1/4W
! R758 1-216-457-00 METAL OXIDE 1.2K 5% 2W F
R761 1-249-432-11 CARBON 18K 5% 1/4W
R762 1-249-437-11 CARBON 47K 5% 1/4W
R767 1-249-435-11 CARBON 33K 5% 1/4W
R781 1-260-100-11 CARBON 1.2K 5% 1/2W
R782 1-260-100-11 CARBON 1.2K 5% 1/2W
R783 1-260-100-11 CARBON 1.2K 5% 1/2W
R784 1-260-100-11 CARBON 1.2K 5% 1/2W
R801 1-249-431-11 CARBON 15K 5% 1/4W
R802 1-249-431-11 CARBON 15K 5% 1/4W
R803 1-249-429-11 CARBON 10K 5% 1/4W
! R804 1-212-982-00 FUSIBLE 100 5% 1/2W F
R851 1-249-431-11 CARBON 15K 5% 1/4W
R852 1-249-435-11 CARBON 33K 5% 1/4W
R853 1-249-429-11 CARBON 10K 5% 1/4W
R854 1-249-397-11 CARBON 22 5% 1/4W F
R855 1-249-441-11 CARBON 100K 5% 1/4W
R856 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
RY741 1-515-920-11 RELAY (24V) (V7770)
RY751 1-515-920-11 RELAY (24V)
< TERMINAL >
TB751 1-537-240-31 TERMINAL BOARD (FRONT SPEAKER)
< VIBRATOR >
X301 1-579-952-21 VIBRATOR, CERAMIC 8MHz (V7770)
************************************************************
* A-4414-708-A MIC/ECHO BOARD, COMPLETE
*************************
< CAPACITOR >
C6001 1-162-306-11 CERAMIC 0.01uF 20% 16V
C6002 1-124-257-00 ELECT 2.2uF 20% 50V
C6003 1-162-306-11 CERAMIC 0.01uF 20% 16V
C6004 1-124-257-00 ELECT 2.2uF 20% 50V
C6005 1-162-294-31 CERAMIC 0.001uF 10% 50V
C6006 1-162-215-31 CERAMIC 47PF 5% 50V
C6007 1-162-290-31 CERAMIC 470PF 10% 50V
C6008 1-126-157-11 ELECT 10uF 20% 16V
C6009 1-124-465-00 ELECT 0.47uF 20% 50V
C6010 1-162-215-31 CERAMIC 47PF 5% 50V
C6011 1-162-282-31 CERAMIC 100PF 10% 50V
C6012 1-126-157-11 ELECT 10uF 20% 16V
C6014 1-124-257-00 ELECT 2.2uF 20% 50V
C6015 1-126-160-11 ELECT 1uF 20% 50V
C6016 1-104-664-11 ELECT 47uF 20% 16V
C6017 1-164-159-11 CERAMIC 0.1uF 50V
C6018 1-104-664-11 ELECT 47uF 20% 16V
C6019 1-136-495-11 FILM 0.068uF 5% 50V
C6020 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C6021 1-162-294-31 CERAMIC 0.001uF 10% 50V
C6022 1-126-160-11 ELECT 1uF 20% 50V
C6023 1-161-494-00 CERAMIC 0.022uF 25V
C6024 1-136-167-00 FILM 0.15uF 5% 50V
C6025 1-126-957-11 ELECT 0.22uF 20% 50V
C6026 1-126-957-11 ELECT 0.22uF 20% 50V
C6027 1-136-495-11 FILM 0.068uF 5% 50V
C6028 1-162-294-31 CERAMIC 0.001uF 10% 50V
C6029 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C6031 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN6001 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D6001 8-719-911-19 DIODE 1SS119
D6002 8-719-911-19 DIODE 1SS119
D6003 8-719-911-19 DIODE 1SS119
< TERMINAL >
* E6001 1-537-738-21 TERMINAL, EARTH
< IC >
IC6001 8-759-634-51 IC M5218AP
IC6002 8-759-450-96 IC M65850P
< JACK >
J6001 1-770-226-11 JACK (LARGE TYPE) (MIX MIC 1)
J6002 1-750-733-11 JACK (LARGE TYPE) (MIX MIC 2)
< COIL >
L6011 1-410-521-11 INDUCTOR 100uH
< RESISTOR >
R6001 1-249-429-11 CARBON 10K 5% 1/4W
R6002 1-249-417-11 CARBON 1K 5% 1/4W F
R6003 1-249-429-11 CARBON 10K 5% 1/4W
R6004 1-249-417-11 CARBON 1K 5% 1/4W F
R6005 1-249-441-11 CARBON 100K 5% 1/4W
R6006 1-249-417-11 CARBON 1K 5% 1/4W F
R6007 1-249-433-11 CARBON 22K 5% 1/4W
R6008 1-249-429-11 CARBON 10K 5% 1/4W
R6009 1-247-885-00 CARBON 180K 5% 1/4W
R6010 1-247-807-31 CARBON 100 5% 1/4W
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
MAIN MIC/ECHO
