Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 63 —
R6011 1-249-433-11 CARBON 22K 5% 1/4W
R6012 1-247-881-00 CARBON 120K 5% 1/4W
R6013 1-249-433-11 CARBON 22K 5% 1/4W
R6014 1-249-433-11 CARBON 22K 5% 1/4W
R6015 1-249-433-11 CARBON 22K 5% 1/4W
R6016 1-249-429-11 CARBON 10K 5% 1/4W
R6017 1-249-437-11 CARBON 47K 5% 1/4W
R6018 1-249-433-11 CARBON 22K 5% 1/4W
R6019 1-249-433-11 CARBON 22K 5% 1/4W
R6020 1-249-431-11 CARBON 15K 5% 1/4W
< VARIABLE RESISTOR >
RV6001 1-225-511-21 RES, VAR, CARBON 50K/50K
(MIC LEVEL/ECHO VOL)
************************************************************
* 1-669-965-11 MOTOR BOARD
*************
< CAPACITOR >
C891 1-162-306-11 CERAMIC 0.01uF 20% 16V
C892 1-124-478-11 ELECT 100uF 20% 25V
C893 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN892 1-568-941-11 PIN, CONNECTOR 3P
< DIODE >
D891 8-719-947-16 DIODE MTZJ-T-72-5.1A
< IC >
IC891 8-759-822-09 IC LB1641
< RESISTOR >
R891 1-249-425-11 CARBON 4.7K 5% 1/4W F
R892 1-249-425-11 CARBON 4.7K 5% 1/4W F
R893 1-249-429-11 CARBON 10K 5% 1/4W
R894 1-249-413-11 CARBON 470 5% 1/4W F
************************************************************
* A-4417-072-A PANEL BOARD, COMPLETE
**********************
(V5550: HK, MY, SP, CH)
* A-4414-737-A PANEL BOARD, COMPLETE (V5550: IA)
**********************
* A-4417-076-A PANEL BOARD, COMPLETE
********************
(V7770: HK, MY, SP, CH)
* A-4417-069-A PANEL BOARD, COMPLETE (V7770: TH)
**********************
* 4-900-849-01 HOLDER (FL)
* 4-932-810-11 CUSHION (FL)
< CAPACITOR >
C501 1-162-205-31 CERAMIC 18PF 5% 50V
C502 1-162-205-31 CERAMIC 18PF 5% 50V
C503 1-104-905-11 CAPACITOR 0.22F 5.5V
C505 1-164-159-11 CERAMIC 0.1uF 50V
C506 1-164-159-11 CERAMIC 0.1uF 50V
C507 1-164-159-11 CERAMIC 0.1uF 50V
C508 1-164-159-11 CERAMIC 0.1uF 50V
C509 1-124-589-11 ELECT 47uF 20% 16V
C510 1-162-306-11 CERAMIC 0.01uF 20% 16V
C513 1-162-284-31 CERAMIC 150PF 10% 50V
C514 1-162-284-31 CERAMIC 150PF 10% 50V
C517 1-162-303-11 CERAMIC 0.0033uF 30% 16V
C518 1-126-157-11 ELECT 10uF 20% 16V
C519 1-126-157-11 ELECT 10uF 20% 16V
C520 1-126-157-11 ELECT 10uF 20% 16V
C521 1-162-306-11 CERAMIC 0.01uF 20% 16V
C522 1-126-157-11 ELECT 10uF 20% 16V
C523 1-126-157-11 ELECT 10uF 20% 16V
C601 1-126-157-11 ELECT 10uF 20% 16V
C602 1-162-306-11 CERAMIC 0.01uF 20% 16V
C603 1-162-294-31 CERAMIC 0.001uF 10% 50V
C604 1-162-294-31 CERAMIC 0.001uF 10% 50V
C605 1-124-261-00 ELECT 10uF 20% 50V
C606 1-124-261-00 ELECT 10uF 20% 50V
C607 1-124-261-00 ELECT 10uF 20% 50V
C608 1-124-589-11 ELECT 47uF 20% 16V
C609 1-162-282-31 CERAMIC 100PF 10% 50V
C610 1-162-288-31 CERAMIC 330PF 10% 50V
C611 1-162-288-31 CERAMIC 330PF 10% 50V
C612 1-162-288-31 CERAMIC 330PF 10% 50V
C613 1-162-288-31 CERAMIC 330PF 10% 50V
C614 1-162-288-31 CERAMIC 330PF 10% 50V
C615 1-162-288-31 CERAMIC 330PF 10% 50V
C616 1-162-288-31 CERAMIC 330PF 10% 50V
C617 1-162-288-31 CERAMIC 330PF 10% 50V
C618 1-162-288-31 CERAMIC 330PF 10% 50V
C619 1-162-288-31 CERAMIC 330PF 10% 50V
C620 1-162-288-31 CERAMIC 330PF 10% 50V
C621 1-162-288-31 CERAMIC 330PF 10% 50V
C622 1-162-288-31 CERAMIC 330PF 10% 50V
C623 1-162-288-31 CERAMIC 330PF 10% 50V
C624 1-162-288-31 CERAMIC 330PF 10% 50V
C625 1-162-288-31 CERAMIC 330PF 10% 50V
< CONNECTOR >
* CN501 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN502 1-778-312-11 PLUG, CONNECTOR (PC BOARD) 30P
CN503 1-691-650-11 SOCKET, CONNECTOR 19P
* CN504 1-565-835-11 SOCKET, CONNECTOR 3P
< DIODE >
D501 8-719-024-99 DIODE 11ES2-NTA2B
D502 8-719-911-19 DIODE 1SS119
D504 8-719-911-19 DIODE 1SS119
D505 8-719-911-19 DIODE 1SS119
D506 8-719-911-19 DIODE 1SS119
MIC/ECHO MOTOR PANEL
To Next Page
