Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 66 —
C952 1-162-294-31 CERAMIC 0.001uF 10% 50V
C953 1-162-282-31 CERAMIC 100PF 10% 50V
C954 1-126-967-11 ELECT 47uF 20% 50V
C955 1-126-967-11 ELECT 47uF 20% 50V
C956 1-136-495-11 FILM 0.068uF 5% 50V
C957 1-136-495-11 FILM 0.068uF 5% 50V
< CONNECTOR >
CN902 1-691-770-11 PLUG (MICRO CONNECTOR) 8P
CN904 1-691-161-11 PIN, CONNECTOR 4P (V7770)
< DIODE >
D809 8-719-028-23 DIODE D3SBA20-4101 (V7770)
D903 8-719-911-19 DIODE 1SS119
D941 8-719-911-19 DIODE 1SS119
D953 8-719-911-19 DIODE 1SS119
< IC >
IC901 8-749-921-68 IC STK-4231MK2 (EXCEPT TH)
IC901 8-749-922-65 IC STK-4221MK2 (TH)
< TRANSISTOR >
Q131 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q181 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q901 8-729-900-36 TRANSISTOR DTC124ES
Q902 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q952 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q971 8-729-900-36 TRANSISTOR DTC124ES
Q972 8-729-119-78 TRANSISTOR 2SC403SP-51
< RESISTOR >
R133 1-249-425-11 CARBON 4.7K 5% 1/4W F
R183 1-249-425-11 CARBON 4.7K 5% 1/4W F
R901 1-249-417-11 CARBON 1K 5% 1/4W F
R902 1-249-437-11 CARBON 47K 5% 1/4W
R903 1-249-413-11 CARBON 470 5% 1/4W F
(EXCEPT TH)
R903 1-249-412-11 CARBON 390 5% 1/4W F
(TH)
R904 1-249-437-11 CARBON 47K 5% 1/4W
R906 1-249-429-11 CARBON 10K 5% 1/4W
R907 1-249-429-11 CARBON 10K 5% 1/4W
R908 1-249-429-11 CARBON 10K 5% 1/4W
R909 1-249-429-11 CARBON 10K 5% 1/4W
R910 1-249-397-11 CARBON 22 5% 1/4W F
R911 1-249-397-11 CARBON 22 5% 1/4W F
R913 1-249-417-11 CARBON 1K 5% 1/4W F
R914 1-249-431-11 CARBON 15K 5% 1/4W
R915 1-249-441-11 CARBON 100K 5% 1/4W
! R920 1-217-156-00 REGISTER 0.22 10% 5W F
! R932 1-212-881-11 FUSIBLE 100 5% 1/4W F
R933 1-249-421-11 CARBON 2.2K 5% 1/4W F
R934 1-249-421-11 CARBON 2.2K 5% 1/4W F
R935 1-249-421-11 CARBON 2.2K 5% 1/4W F
R936 1-249-421-11 CARBON 2.2K 5% 1/4W F
R937 1-249-429-11 CARBON 10K 5% 1/4W
(EXCEPT TH)
R937 1-249-437-11 CARBON 47K 5% 1/4W
(TH)
R938 1-247-885-00 CARBON 180K 5% 1/4W
R940 1-249-429-11 CARBON 10K 5% 1/4W
R941 1-249-429-11 CARBON 10K 5% 1/4W
R942 1-249-413-11 CARBON 470 5% 1/4W F
! R943 1-212-881-11 FUSIBLE 100 5% 1/4W F
R945 1-249-417-11 CARBON 1K 5% 1/4W F
R951 1-249-417-11 CARBON 1K 5% 1/4W F
R952 1-249-437-11 CARBON 47K 5% 1/4W
R953 1-249-413-11 CARBON 470 5% 1/4W F
(EXCEPT TH)
R953 1-249-412-11 CARBON 390 5% 1/4W F
(TH)
R954 1-249-437-11 CARBON 47K 5% 1/4W
R956 1-249-429-11 CARBON 10K 5% 1/4W
R957 1-249-429-11 CARBON 10K 5% 1/4W
R958 1-249-429-11 CARBON 10K 5% 1/4W
R959 1-249-429-11 CARBON 10K 5% 1/4W
R960 1-249-397-11 CARBON 22 5% 1/4W F
R961 1-249-397-11 CARBON 22 5% 1/4W F
R963 1-249-417-11 CARBON 1K 5% 1/4W F
R964 1-249-431-11 CARBON 15K 5% 1/4W
R965 1-249-441-11 CARBON 100K 5% 1/4W
! R970 1-217-156-00 REGISTER 0.22 10% 5W F
R971 1-249-441-11 CARBON 100K 5% 1/4W
R972 1-247-885-00 CARBON 180K 5% 1/4W
R973 1-249-441-11 CARBON 100K 5% 1/4W
! R974 1-212-849-00 FUSIBLE 4.7 5% 1/4W F
< THERMISTOR(POSITIVE) >
THP901 1-807-796-11 THERMISTOR
************************************************************
* 1-669-953-11 PRIMARY BOARD
**************
1-533-293-11 FUSE HOLDER
< CONNECTOR >
CN871 1-564-321-00 PIN, CONNECTOR 2P
< FUSE >
! F873 1-532-506-51 FUSE TIME LAG 6.3A
< SWITCH >
! S871 1-771-291-11 SWITCH, POWER (VOLTAGE SELECTOR)
(HK, MY, SP, IA)
************************************************************
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
POWER AMP PRIMARY
