Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 67 —
* 1-669-954-11 SECONDARY BOARD
*****************
1-533-293-11 FUSE HOLDER
< CONNECTOR >
* CN872 1-564-518-11 PLUG, CONNECTOR 3P (V7770)
< FUSE >
! F874 1-532-506-51 FUSE TIME LAG 6.3A, 250V
! F875 1-532-506-51 FUSE TIME LAG 6.3A, 250V
! F876 1-532-505-51 FUSE TIME LAG 5A, 250V (V7770)
! F877 1-532-505-51 FUSE TIME LAG 5A, 250V (V7770)
< RESISTOR >
! R871 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R872 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R873 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R874 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
************************************************************
* A-4414-219-A SURR AMP BOARD, COMPLETE (V7770)
**************************
< CAPACITOR >
C4000 1-162-306-11 CERAMIC 0.01uF 20% 16V
C4001 1-126-961-11 ELECT 2.2uF 20% 50V
C4002 1-162-294-31 CERAMIC 0.001uF 10% 50V
C4003 1-162-282-31 CERAMIC 100PF 10% 50V
C4004 1-126-964-11 ELECT 10uF 20% 50V
C4005 1-126-964-11 ELECT 10uF 20% 50V
C4006 1-136-165-00 FILM 0.1uF 5% 50V
C4007 1-136-165-00 FILM 0.1uF 5% 50V
C4010 1-126-967-11 ELECT 47uF 20% 50V
C4011 1-126-963-11 ELECT 4.7uF 20% 50V
C4012 1-126-965-11 ELECT 22uF 20% 50V
C4013 1-126-967-11 ELECT 47uF 20% 50V
C4040 1-126-963-11 ELECT 4.7uF 20% 50V
C4051 1-126-961-11 ELECT 2.2uF 20% 50V
C4052 1-162-294-31 CERAMIC 0.001uF 10% 50V
C4053 1-162-282-31 CERAMIC 100PF 10% 50V
C4054 1-126-964-11 ELECT 10uF 20% 50V
C4055 1-126-964-11 ELECT 10uF 20% 50V
C4056 1-136-165-00 FILM 0.1uF 5% 50V
C4057 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
* CN4002 1-564-519-11 PLUG, CONNECTOR 4P
* CN4003 1-691-174-11 CONNECTOR (BOARD TO BOARD) 4P
< DIODE >
D4003 8-719-911-19 DIODE 1SS119
D4053 8-719-911-19 DIODE 1SS119
< IC >
IC4001 8-749-900-96 IC STK-4142MK2
< TRANSISTOR >
Q4002 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q4052 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R4001 1-249-417-11 CARBON 1K 5% 1/4W F
R4002 1-249-437-11 CARBON 47K 5% 1/4W
R4003 1-249-413-11 CARBON 470 5% 1/4W F
R4004 1-249-437-11 CARBON 47K 5% 1/4W
R4006 1-249-425-11 CARBON 4.7K 5% 1/4W F
R4007 1-249-425-11 CARBON 4.7K 5% 1/4W F
R4008 1-249-425-11 CARBON 4.7K 5% 1/4W F
R4009 1-249-425-11 CARBON 4.7K 5% 1/4W F
R4010 1-249-397-11 CARBON 22 5% 1/4W F
R4011 1-249-397-11 CARBON 22 5% 1/4W F
R4013 1-249-417-11 CARBON 1K 5% 1/4W F
R4014 1-249-431-11 CARBON 15K 5% 1/4W
R4015 1-249-441-11 CARBON 100K 5% 1/4W
! R4020 1-208-602-11 REGISTER 0.22 10% 2W F
! R4021 1-217-641-00 FUSIBLE 4.7 5% 1/4W F
! R4032 1-212-881-11 FUSIBLE 100 5% 1/4W F
R4033 1-249-421-11 CARBON 2.2K 5% 1/4W F
R4034 1-249-421-11 CARBON 2.2K 5% 1/4W F
R4035 1-249-421-11 CARBON 2.2K 5% 1/4W F
R4036 1-249-421-11 CARBON 2.2K 5% 1/4W F
! R4043 1-212-881-11 FUSIBLE 100 5% 1/4W F
R4051 1-249-417-11 CARBON 1K 5% 1/4W F
R4052 1-249-437-11 CARBON 47K 5% 1/4W
R4053 1-249-413-11 CARBON 470 5% 1/4W F
R4054 1-249-437-11 CARBON 47K 5% 1/4W
R4056 1-249-425-11 CARBON 4.7K 5% 1/4W F
R4057 1-249-425-11 CARBON 4.7K 5% 1/4W F
R4058 1-249-425-11 CARBON 4.7K 5% 1/4W F
R4059 1-249-425-11 CARBON 4.7K 5% 1/4W F
R4060 1-249-397-11 CARBON 22 5% 1/4W F
R4061 1-249-397-11 CARBON 22 5% 1/4W F
R4063 1-249-417-11 CARBON 1K 5% 1/4W F
R4064 1-249-431-11 CARBON 15K 5% 1/4W
R4065 1-249-441-11 CARBON 100K 5% 1/4W
! R4070 1-208-602-11 REGISTER 0.22 10% 2W F
************************************************************
* 1-669-963-11 SURR SPK BOARD
***************
< CAPACITOR >
C202 1-104-666-11 ELECT 220uF 20% 25V
C203 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
* CN201 1-569-505-11 PIN, CONNECTOR 10P
CN202 1-564-506-11 PLUG, CONNECTOR 3P
CN781 1-506-468-11 PIN, CONNECTOR 3P
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
SECONDARY SURR AMP SURR SPK
