Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
RY106 1-515-614-11 RELAY
RY107 1-515-614-11 RELAY
RY108 1-515-614-11 RELAY
************************************************************
* 1-669-482-11 LED BOARD
**********
< CONNECTOR >
* CN806 1-563-381-11 SOCKET, CONNECTOR 11P
< DIODE >
D914 8-719-046-38 LED SEL5821A-TH8F (TAPE1/DAT)
D915 8-719-046-38 LED SEL5821A-TH8F (TAPE2/MD)
D916 8-719-046-38 LED SEL5821A-TH8F (AUX)
D917 8-719-046-38 LED SEL5821A-TH8F (CD)
D918 8-719-046-38 LED SEL5821A-TH8F (TUNER)
D919 8-719-046-38 LED SEL5821A-TH8F (PHONO)
D920 8-719-046-38 LED SEL5821A-TH8F (SOURCE DIRECT)
D921 8-719-046-38 LED SEL5821A-TH8F (MUTING)
D922 8-719-046-38 LED SEL5821A-TH8F (TAPE MONITOR)
< RESISTOR >
R932 1-249-409-11 CARBON 220 5% 1/4W
************************************************************
* A-4407-669-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C500 1-102-973-00 CERAMIC 100PF 5% 50V
C501 1-128-197-11 ELECT 10uF 20% 50V
C502 1-101-880-00 CERAMIC 47PF 5% 50V
C503 1-125-852-11 FILM 330PF 5% 50V
C504 1-126-023-11 ELECT 100uF 20% 16V
C505 1-107-587-11 CERAMIC 7PF 0.5PF 500V
C506 1-126-023-11 ELECT 100uF 20% 16V
C507 1-126-023-11 ELECT 100uF 20% 16V
C508 1-126-023-11 ELECT 100uF 20% 16V
C509 1-125-842-11 FILM 4PF 10% 50V
C510 1-128-200-11 ELECT 47uF 20% 63V
C511 1-102-978-00 CERAMIC 220PF 5% 50V
C512 1-136-163-00 FILM 0.068uF 5% 50V
C513 1-136-163-00 FILM 0.068uF 5% 50V
C517 1-126-023-11 ELECT 100uF 20% 16V
C600 1-102-973-00 CERAMIC 100PF 5% 50V
C601 1-128-197-11 ELECT 10uF 20% 50V
C602 1-101-880-00 CERAMIC 47PF 5% 50V
C603 1-125-852-11 FILM 330PF 5% 50V
C604 1-126-023-11 ELECT 100uF 20% 16V
C605 1-107-587-11 CERAMIC 7PF 0.5PF 500V
C606 1-126-023-11 ELECT 100uF 20% 16V
C607 1-126-023-11 ELECT 100uF 20% 16V
C608 1-126-023-11 ELECT 100uF 20% 16V
C609 1-125-842-11 FILM 4PF 10% 50V
C610 1-128-200-11 ELECT 47uF 20% 63V
C611 1-102-978-00 CERAMIC 220PF 5% 50V
C612 1-136-163-00 FILM 0.068uF 5% 50V
C613 1-136-163-00 FILM 0.068uF 5% 50V
C617 1-126-023-11 ELECT 100uF 20% 16V
C712 1-128-552-51 ELECT 47uF 20% 63V
C713 1-126-933-11 ELECT 100uF 20% 16V
C714 1-126-964-11 ELECT 10uF 20% 50V
C720 1-110-397-11 ELECT 1000uF 20% 63V
C721 1-110-397-11 ELECT 1000uF 20% 63V
< CONNECTOR >
CN500 1-564-506-11 PLUG, CONNECTOR 3P
CN503 1-564-510-11 PLUG (MICRO CONNECTOR) 6P
CN600 1-564-506-11 PLUG, CONNECTOR 3P
CN700 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
< DIODE >
D500 8-719-911-19 DIODE 1SS119
D501 8-719-911-19 DIODE 1SS119
D502 8-719-911-19 DIODE 1SS119
D503 8-719-933-39 DIODE HZS6C1L
D504 8-719-911-19 DIODE 1SS119
D505 8-719-911-19 DIODE 1SS119
D506 8-719-310-61 LED SEL1510C-D
D600 8-719-911-19 DIODE 1SS119
D601 8-719-911-19 DIODE 1SS119
D602 8-719-911-19 DIODE 1SS119
D603 8-719-933-39 DIODE HZS6C1L
D604 8-719-911-19 DIODE 1SS119
D605 8-719-911-19 DIODE 1SS119
D606 8-719-310-61 LED SEL1510C-D
D703 8-719-933-39 DIODE HZS6C1L
D704 8-719-911-19 DIODE 1SS119
D720 8-719-024-99 DIODE 11ES2-NTA2B
D721 8-719-024-99 DIODE 11ES2-NTA2B
< BRIDGE >
JWH711 4-999-918-01 BRIDGE (PC-BOARD)
JWH712 4-999-918-01 BRIDGE (PC-BOARD)
JWH713 4-999-918-01 BRIDGE (PC-BOARD)
JWH714 4-999-918-01 BRIDGE (PC-BOARD)
JWH715 4-999-918-01 BRIDGE (PC-BOARD)
< COIL >
L720 1-428-203-11 COIL, AIR-CORE
L721 1-428-203-11 COIL, AIR-CORE
< TRANSISTOR >
Q500 8-729-045-15 TRANSISTOR 2SC5169-FG
Q501 8-729-201-53 TRANSISTOR 2SA1015-GR
Q502 8-729-201-53 TRANSISTOR 2SA1015-GR
Q503 8-729-201-53 TRANSISTOR 2SA1015-GR
Q504 8-729-104-91 TRANSISTOR 2SA1383
Q505 8-729-202-67 FET 2SK246-GR3
Q506 8-729-119-78 TRANSISTOR 2SC403SP-51
Q507 8-729-104-18 TRANSISTOR 2SC3514-Q
Q508 8-729-119-78 TRANSISTOR 2SC403SP-51
Q509 8-729-018-19 TRANSISTOR 2SK2013-Y
Q510 8-729-018-21 TRANSISTOR 2SJ313-Y
Q511 8-729-015-30 FET 2SK1530-Y
