Sony TA-FA30ES - Disassembly Procedures; Front Panel and Case Removal; Sub Panel Section Disassembly

– 4 –
6 connector
(CN2)
4 connector
(CN700)
1 connecto
r
(CN103)
3 connector
(CN303)
2 connector
(
CN102
)
7 two screws
(3 × 8)
7 three screws
(3 × 8)
7 two screws
(3 × 8)
7 four screws
(3 × 8)
7 two screws
(3 × 8)
5 connector
(CN503)
8 sub panel section
CASE, FRONT PANEL
SUB PANEL SECTION
Note: Follow the disassembly procedure in the numerical order given.
SECTION 2
DISASSEMBLY
1 two screws
(CASE 3 TP2)
1 screw
(CASE 3 TP2)
1 two screws
(CASE 3 TP2)
2 case
(413235)
1 two screws
(CASE 3 TP2)
5 three screws
(3
× 8)
5 four screws
(3
× 8)
6 front panel
3 knob (SEL)
4 knob (VOL)
