REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
9-18
BK
R951 1-216-073-00 RES,CHIP 10K 5% 1/10W
R952 1-216-073-00 RES,CHIP 10K 5% 1/10W
R953 1-216-073-00 RES,CHIP 10K 5% 1/10W
R955 1-216-073-00 RES,CHIP 10K 5% 1/10W
R956 1-216-073-00 RES,CHIP 10K 5% 1/10W
R958 1-216-073-00 RES,CHIP 10K 5% 1/10W
R959 1-216-073-00 RES,CHIP 10K 5% 1/10W
R960 1-216-049-91 RES,CHIP 1K 5% 1/10W
R962 1-216-097-91 RES,CHIP 100K 5% 1/10W
R970 1-216-073-00 RES,CHIP 10K 5% 1/10W
R980 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1001 1-216-685-11 METAL CHIP 27K 0.50% 1/10W
R1002 1-216-627-11 METAL CHIP 100 0.50% 1/10W
R1003 1-216-685-11 METAL CHIP 27K 0.50% 1/10W
R1004 1-216-627-11 METAL CHIP 100 0.50% 1/10W
R1005 1-216-685-11 METAL CHIP 27K 0.50% 1/10W
R1006 1-216-627-11 METAL CHIP 100 0.50% 1/10W
R1007 1-216-685-11 METAL CHIP 27K 0.50% 1/10W
R1008 1-216-627-11 METAL CHIP 100 0.50% 1/10W
R1009 1-216-685-11 METAL CHIP 27K 0.50% 1/10W
R1010 1-216-627-11 METAL CHIP 100 0.50% 1/10W
R1011 1-216-685-11 METAL CHIP 27K 0.50% 1/10W
R1012 1-216-627-11 METAL CHIP 100 0.50% 1/10W
R1013 1-216-685-11 METAL CHIP 27K 0.50% 1/10W
R1014 1-216-627-11 METAL CHIP 100 0.50% 1/10W
R1015 1-216-685-11 METAL CHIP 27K 0.50% 1/10W
R1016 1-216-627-11 METAL CHIP 100 0.50% 1/10W
R1017 1-216-685-11 METAL CHIP 27K 0.50% 1/10W
R1018 1-216-627-11 METAL CHIP 100 0.50% 1/10W
R1019 1-216-685-11 METAL CHIP 27K 0.50% 1/10W
R1020 1-216-627-11 METAL CHIP 100 0.50% 1/10W
R1021 1-216-685-11 METAL CHIP 27K 0.50% 1/10W
R1022 1-216-627-11 METAL CHIP 100 0.50% 1/10W
R1023 1-216-685-11 METAL CHIP 27K 0.50% 1/10W
R1024 1-216-627-11 METAL CHIP 100 0.50% 1/10W
<TERMINAL BOARD>
TB1 1-694-371-11 TERMINAL BOARD ASSY, I/O
<THERMISTOR>
TH300 1-807-796-11 THERMISTOR
<CRYSTAL>
X900 1-578-689-21 VIBRATOR
*************************************************************
* A-1331-724-A C MOUNT
****************
<CAPACITOR>
C504 1-162-114-00 CERAMIC 0.0047MF 2KV
C505 1-162-114-00 CERAMIC 0.0047MF 2KV
C506 1-162-114-00 CERAMIC 0.0047MF 2KV
C507 1-107-888-11 ELECT 47MF 20% 25V
C508 1-107-888-11 ELECT 47MF 20% 25V
C601 1-104-653-11 ELECT 220MF 20% 16V
C602 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C701 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C702 1-107-960-11 ELECT 4.7MF 20% 160V
C703 1-107-943-11 ELECT 10MF 20% 160V
C704 1-107-364-11 MYLAR 0.01MF 10% 200V
C705 1-107-888-11 ELECT 47MF 20% 25V
<CONNECTOR>
CN501 1-508-786-00 PIN, CONNECTOR (5MM PITCH) 2P
CN502 1-695-915-11 TAB (CONTACT)
CN503 1-766-241-11 PIN, CONNECTOR (PC BOARD) 3P
CN504 * 1-564-507-11 PLUG, CONNECTOR 4P
CN505 * 1-564-507-11 PLUG, CONNECTOR 4P
CN506 * 1-564-507-11 PLUG, CONNECTOR 4P
CN507 * 1-564-506-11 PLUG, CONNECTOR 3P
CN508 * 1-564-511-11 PLUG, CONNECTOR 8P
<DIODE>
D501 8-719-979-58 DIODE EGP10D
D601 8-719-404-49 DIODE MA111
D602 8-719-404-49 DIODE MA111
D603 8-719-404-49 DIODE MA111
D604 8-719-404-49 DIODE MA111
D701 8-719-158-55 DIODE RD15SB
<IC>
IC601 8-759-983-69 IC LM358PS
IC701 8-759-346-42 IC TDA6101Q/N3
<SOCKET>
J501 ! 1-251-116-11 SOCKET, CRT
<CHIP CONDUCTOR>
JR501 1-216-295-91 SHORT 0
JR502 1-216-295-91 SHORT 0
JR503 1-216-295-91 SHORT 0
JR504 1-216-295-91 SHORT 0
JR505 1-216-295-91 SHORT 0
JR506 1-216-295-91 SHORT 0
JR507 1-216-295-91 SHORT 0
JR508 1-216-295-91 SHORT 0
<COIL>
L501 1-408-595-31 INDUCTOR 2.2µH
L502 1-408-595-31 INDUCTOR 2.2µH
L503 1-408-595-31 INDUCTOR 2.2µH
C
