Sony TRINITRON BVM-14G1A - Page 131

9-19
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
C
<TRANSISTOR>
Q601 8-729-020-07 TRANSISTOR 2SC4686A(LBSONY)
Q602 8-729-020-07 TRANSISTOR 2SC4686A(LBSONY)
Q603 8-729-020-07 TRANSISTOR 2SC4686A(LBSONY)
<RESISTOR>
R501 1-219-745-11 CARBON 470 5% 1/2W
R502 1-219-745-11 CARBON 470 5% 1/2W
R503 1-219-745-11 CARBON 470 5% 1/2W
R504 1-219-746-11 CARBON 1K 5% 1/2W
R505 1-219-746-11 CARBON 1K 5% 1/2W
R506 1-219-746-11 CARBON 1K 5% 1/2W
R507 1-219-696-11 METAL OXIDE 30M 5% 1W
R508 1-219-755-11 CARBON 10M 5% 1/2W
R509 1-219-759-11 CARBON 1M 5% 1/2W
R510 1-219-743-11 CARBON 100 5% 1/2W
R511 1-219-743-11 CARBON 100 5% 1/2W
R512 1-219-743-11 CARBON 100 5% 1/2W
R513 1-219-744-11 CARBON 220 5% 1/2W
R514 1-219-744-11 CARBON 220 5% 1/2W
R515 1-219-744-11 CARBON 220 5% 1/2W
R516 1-219-753-11 CARBON 220K 5% 1/2W
R601 1-216-103-00 RES,CHIP 180K 5% 1/10W
R602 1-216-097-91 RES,CHIP 100K 5% 1/10W
R603 1-216-093-00 RES,CHIP 68K 5% 1/10W
R604 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R605 1-216-097-91 RES,CHIP 100K 5% 1/10W
R606 1-216-073-00 RES,CHIP 10K 5% 1/10W
R607 1-208-612-11 METAL OXIDE 10M 5% 1W
R608 1-208-612-11 METAL OXIDE 10M 5% 1W
R609 1-216-073-00 RES,CHIP 10K 5% 1/10W
R610 1-216-103-00 RES,CHIP 180K 5% 1/10W
R611 1-216-073-00 RES,CHIP 10K 5% 1/10W
R612 1-216-073-00 RES,CHIP 10K 5% 1/10W
R613 1-216-111-00 RES,CHIP 390K 5% 1/10W
R614 1-219-759-11 CARBON 1M 5% 1/2W
R615 1-216-081-00 RES,CHIP 22K 5% 1/10W
R701 1-216-655-11 METAL CHIP 1.5K 0.50% 1/10W
R702 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R703 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R704 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
R705 1-214-903-31 METAL 39K 1% 1/2W
R706 1-216-049-91 RES,CHIP 1K 5% 1/10W
R707 1-216-113-00 RES,CHIP 470K 5% 1/10W
R708 1-219-743-11 CARBON 100 5% 1/2W
<VARIABLE RESISTOR>
RV501 ! 1-223-410-11 RES, ADJ, METAL FILM 110M
<SPARK GAP>
SG501 1-519-422-11 GAP, SPARK
SG502 1-519-421-11 GAP, DISCHARGE
SG503 1-519-421-11 GAP, DISCHARGE
SG504 1-519-421-11 GAP, DISCHARGE
SG505 1-519-421-11 GAP, DISCHARGE
SG506 1-519-421-11 GAP, DISCHARGE
SG507 1-519-421-11 GAP, DISCHARGE
SG508 1-519-422-11 GAP, SPARK
*************************************************************
* A-1346-666-A E COMPL (14G1/14G5)
*********
* A-1346-667-A E COMPL (20G1)
*********
* X-4033-108-1 HEAT SINK ASSY, DEF
* 3-648-057-00 NUT (ISO-4), U
* 4-050-794-01 INSULATOR
* 4-050-814-01 SHIELD, PWB
* 4-053-101-01 SPACER, DY CONNECTOR
* 4-381-905-01 SPRING (D)
4-381-907-01 INSULATOR (A)
4-382-854-01 SCREW (M3X8), P, SW (+)
7-322-065-19 RUBBER, SILICON RTV (KE490W)
7-682-566-04 SCREW +B 4X20
7-682-647-09 SCREW +PS 3X6
<CAPACITOR>
C001 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C004 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C005 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C006 1-110-501-11 CERAMIC CHIP 0.33MF 10% 16V
C008 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C009 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C010 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C011 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C012 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C013 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C014 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C015 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C016 1-164-346-11 CERAMIC CHIP 1MF 16V
C017 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C018 1-110-501-11 CERAMIC CHIP 0.33MF 10% 16V
C019 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C020 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C021 1-164-695-11 CERAMIC CHIP 0.0022MF 5% 50V
C022 1-107-901-11 ELECT 0.47MF 20% 50V
C023 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C024 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C031 1-128-528-11 ELECT 470MF 20% 25V
C032 1-128-528-11 ELECT 470MF 20% 25V
C033 1-107-910-11 ELECT 100MF 20% 50V
C034 1-137-399-11 FILM 0.1MF 5% 100V
C036 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C051 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C052 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C053 1-102-030-00 CERAMIC 330PF 10% 500V
C054 1-129-765-00 FILM 0.047MF 5% 200V
C055 ! 1-162-116-00 CERAMIC 680PF 10% 2KV
C056 ! 1-162-134-11 CERAMIC 470PF 10% 2KV
C057 1-136-081-00 FILM 0.012MF 3% 2KV
C058 ! 1-162-116-00 CERAMIC 680PF 10% 2KV
C061 1-123-024-21 ELECT 33MF 160V
C062 1-137-417-11 MYLAR 0.0047MF 10% 200V
C063 1-107-995-11 ELECT 100MF 0 160V
C064 1-109-921-11 CERAMIC 0.0015MF 10% 500V
E
