9-31
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
G
R809 1-216-073-00 RES,CHIP 10K 5% 1/10W
R811 1-216-661-11 METAL CHIP 2.7K 0.50% 1/10W
R812 1-216-658-11 METAL CHIP 2K 0.50% 1/10W
R813 1-216-049-91 RES,CHIP 1K 5% 1/10W
R814 1-214-921-00 METAL 220K 1% 1/2W
R815 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R816 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R817 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
R818 1-216-683-11 METAL CHIP 22K 0.50% 1/10W
R819 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R820 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R821 1-216-073-00 RES,CHIP 10K 5% 1/10W
R823 1-216-049-91 RES,CHIP 1K 5% 1/10W
R824 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R825 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R826 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R827 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R830 1-216-025-91 RES,CHIP 100 5% 1/10W
R831 1-216-025-91 RES,CHIP 100 5% 1/10W
R832 1-216-025-91 RES,CHIP 100 5% 1/10W
R833 1-216-025-91 RES,CHIP 100 5% 1/10W
R901 1-202-725-00 SOLID 3.3M 20% 1/2W
R902 1-202-725-00 SOLID 3.3M 20% 1/2W
R903 1-216-073-00 RES,CHIP 10K 5% 1/10W
R904 1-216-073-00 RES,CHIP 10K 5% 1/10W
R906 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R907 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
<RELAY>
RY 1 ! 1-515-738-11 RELAY
RY901 ! 1-515-738-11 RELAY
<SWITCH>
S901 ! 1-762-300-11 SWITCH, AC POWER SEESAW
<TRANSFORMER>
T1 ! 1-424-461-11 TRANSFORMER, LINE FILTER
T2 ! 1-424-461-11 TRANSFORMER, LINE FILTER
T3 ! 1-429-283-11 TRANSFORMER, CONVERTER (PFT)
T201 ! 1-431-703-11 TRANSFORMER, CONVERTER
T301 ! 1-431-704-11 TRANSFORMER, CONVERTER
<THERMISTOR>
THP1 ! 1-808-059-31 THERMISTOR, POSITIVE
<TEST PIN>
TP31 1-537-864-11 PIN, POST
TP32 1-537-864-11 PIN, POST
TP33 1-537-864-11 PIN, POST
TP201 1-537-864-11 PIN, POST
TP202 1-537-864-11 PIN, POST
TP207 1-537-864-11 PIN, POST
TP301 1-537-864-11 PIN, POST
TP302 1-537-864-11 PIN, POST
TP303 1-537-864-11 PIN, POST
TP304 1-537-864-11 PIN, POST
TP305 1-537-864-11 PIN, POST
<VARISTOR>
VDR1 ! 1-801-073-31 VARISTOR TNR14V471K660
VDR2 ! 1-810-622-11 VARISTOR
*************************************************************
* A-1372-133-A MOUNTED PWB, HA (14G5,BKM-10R)
****************
<CAPACITOR>
C201 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C202 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C203 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C204 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C205 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C206 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C207 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C211 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C212 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C213 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C214 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C215 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C216 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C217 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C301 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C302 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C303 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C304 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C305 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C306 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C307 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C308 1-163-031-11 CERAMIC CHIP 0.01MF 50V
<CONNECTOR>
CN201 * 1-564-005-11 PIN, CONNECTOR 6P
CN202 * 1-564-009-11 PIN, CONNECTOR 10P
<DIODE>
D201 8-719-404-49 DIODE MA111
D202 8-719-404-49 DIODE MA111
D203 8-719-404-49 DIODE MA111
D204 8-719-404-49 DIODE MA111
D205 8-719-404-49 DIODE MA111
D206 8-719-404-49 DIODE MA111
D207 8-719-404-49 DIODE MA111
D208 8-719-404-49 DIODE MA111
D209 8-719-404-49 DIODE MA111
D210 8-719-404-49 DIODE MA111
D211 8-719-404-49 DIODE MA111
D212 8-719-404-49 DIODE MA111
D213 8-719-404-49 DIODE MA111
D214 8-719-404-49 DIODE MA111
D215 8-719-404-49 DIODE MA111
D216 8-719-404-49 DIODE MA111
D217 8-719-404-49 DIODE MA111
D218 8-719-404-49 DIODE MA111
D219 8-719-404-49 DIODE MA111
D220 8-719-404-49 DIODE MA111
HA
