REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
9-32
D221 8-719-404-49 DIODE MA111
D222 8-719-404-49 DIODE MA111
D223 8-719-987-45 DIODE CL-155Y/PG-CD
D224 8-719-987-45 DIODE CL-155Y/PG-CD
D225 8-719-987-45 DIODE CL-155Y/PG-CD
D226 8-719-987-45 DIODE CL-155Y/PG-CD
D231 8-719-158-19 DIODE RD6.2SB
<IC>
IC201 8-752-842-86 IC CXP2003M
IC202 8-752-842-86 IC CXP2003M
<TRANSISTOR>
Q201 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q202 8-729-921-12 TRANSISTOR 2SD1834
Q203 8-729-921-12 TRANSISTOR 2SD1834
<RESISTOR>
R201 1-216-043-91 RES,CHIP 560 5% 1/10W
R202 1-216-043-91 RES,CHIP 560 5% 1/10W
R203 1-216-043-91 RES,CHIP 560 5% 1/10W
R204 1-216-043-91 RES,CHIP 560 5% 1/10W
R205 1-216-097-91 RES,CHIP 100K 5% 1/10W
R206 1-216-049-91 RES,CHIP 1K 5% 1/10W
R207 1-216-049-91 RES,CHIP 1K 5% 1/10W
R208 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R209 1-216-049-91 RES,CHIP 1K 5% 1/10W
R210 1-216-097-91 RES,CHIP 100K 5% 1/10W
R211 1-216-085-00 RES,CHIP 33K 5% 1/10W
R212 1-216-095-00 RES,CHIP 82K 5% 1/10W
R213 1-216-085-00 RES,CHIP 33K 5% 1/10W
R214 1-216-095-00 RES,CHIP 82K 5% 1/10W
R215 1-216-089-91 RES,CHIP 47K 5% 1/10W
R216 1-216-089-91 RES,CHIP 47K 5% 1/10W
R217 1-216-089-91 RES,CHIP 47K 5% 1/10W
R301 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R302 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R303 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R304 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R305 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R306 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R307 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R308 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
<SWITCH>
S201 1-692-037-31 SWITCH, KEY BOARD (POWER)
S202 1-692-037-31 SWITCH, KEY BOARD (DEGAUSS)
S203 1-692-037-31 SWITCH, KEY BOARD (1)
S204 1-692-037-31 SWITCH, KEY BOARD (2)
S205 1-692-037-31 SWITCH, KEY BOARD (3)
S206 1-692-037-31 SWITCH, KEY BOARD (Del)
S207 1-692-037-31 SWITCH, KEY BOARD (4)
S208 1-692-037-31 SWITCH, KEY BOARD (5)
S209 1-692-037-31 SWITCH, KEY BOARD (6)
S210 1-692-037-31 SWITCH, KEY BOARD (0)
S211 1-692-037-31 SWITCH, KEY BOARD (7)
S212 1-692-037-31 SWITCH, KEY BOARD (8)
S213 1-692-037-31 SWITCH, KEY BOARD (9)
S214 1-692-037-31 SWITCH, KEY BOARD (Ent)
S215 1-692-037-31 SWITCH, KEY BOARD (MANUAL CONTRAST)
S216 1-692-037-31 SWITCH, KEY BOARD (MANUAL BRIGHT)
S217 1-692-037-31 SWITCH, KEY BOARD (MANUAL CHROMA)
S218 1-692-037-31 SWITCH, KEY BOARD (MANUAL PHASE)
S219 1-692-037-31 SWITCH, KEY BOARD (MENU)
S220 1-692-037-31 SWITCH, KEY BOARD (ENTER)
S221 1-692-037-31 SWITCH, KEY BOARD (UP)
S222 1-692-037-31 SWITCH, KEY BOARD (DOWN)
S231 1-473-469-11 ENCODER, ROTARY (CONTRAST)
S232 1-473-469-11 ENCODER, ROTARY (BRIGHT)
S233 1-473-469-11 ENCODER, ROTARY (CHROMA)
S234 1-473-469-11 ENCODER, ROTARY (PHASE)
*************************************************************
* A-1372-134-A MOUNTED PWB, HB (14G5,BKM-10R)
****************
<CAPACITOR>
C101 1-126-391-11 ELECT CHIP 47MF 20% 6.3V
C102 1-126-391-11 ELECT CHIP 47MF 20% 6.3V
C111 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C112 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C113 1-163-031-11 CERAMIC CHIP 0.01MF 50V
<CONNECTOR>
CN101 1-506-471-11 PIN, CONNECTOR 6P
<DIODE>
D101 8-719-404-49 DIODE MA111
D102 8-719-404-49 DIODE MA111
D103 8-719-404-49 DIODE MA111
D104 8-719-404-49 DIODE MA111
D105 8-719-404-49 DIODE MA111
D106 8-719-404-49 DIODE MA111
D107 8-719-404-49 DIODE MA111
D108 8-719-404-49 DIODE MA111
D109 8-719-404-49 DIODE MA111
D110 8-719-404-49 DIODE MA111
D111 8-719-158-19 DIODE RD6.2SB
D121 8-719-987-45 DIODE CL-155Y/PG-CD
D122 8-719-987-45 DIODE CL-155Y/PG-CD
D123 8-719-987-45 DIODE CL-155Y/PG-CD
D124 8-719-987-45 DIODE CL-155Y/PG-CD
D125 8-719-987-45 DIODE CL-155Y/PG-CD
D126 8-719-987-45 DIODE CL-155Y/PG-CD
D127 8-719-987-45 DIODE CL-155Y/PG-CD
D128 8-719-987-45 DIODE CL-155Y/PG-CD
D129 8-719-987-45 DIODE CL-155Y/PG-CD
D130 8-719-987-45 DIODE CL-155Y/PG-CD
<IC>
IC101 8-752-842-86 IC CXP2003M
IC102 8-752-842-86 IC CXP2003M
<TRANSISTOR>
Q101 8-729-921-12 TRANSISTOR 2SD1834
Q102 8-729-921-12 TRANSISTOR 2SD1834
HA HB
