Sony TRINITRON BVM-14G1A - Page 145

9-33
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
Q103 1-801-806-11 TRANSISTOR DTC144EKA-T146
<RESISTOR>
R101 1-216-043-91 RES,CHIP 560 5% 1/10W
R102 1-216-043-91 RES,CHIP 560 5% 1/10W
R103 1-216-043-91 RES,CHIP 560 5% 1/10W
R104 1-216-043-91 RES,CHIP 560 5% 1/10W
R105 1-216-043-91 RES,CHIP 560 5% 1/10W
R106 1-216-043-91 RES,CHIP 560 5% 1/10W
R107 1-216-043-91 RES,CHIP 560 5% 1/10W
R108 1-216-043-91 RES,CHIP 560 5% 1/10W
R109 1-216-043-91 RES,CHIP 560 5% 1/10W
R110 1-216-043-91 RES,CHIP 560 5% 1/10W
R112 1-216-097-91 RES,CHIP 100K 5% 1/10W
R113 1-216-049-91 RES,CHIP 1K 5% 1/10W
R114 1-216-049-91 RES,CHIP 1K 5% 1/10W
R115 1-216-049-91 RES,CHIP 1K 5% 1/10W
R116 1-216-097-91 RES,CHIP 100K 5% 1/10W
R117 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R121 1-216-085-00 RES,CHIP 33K 5% 1/10W
R122 1-216-095-00 RES,CHIP 82K 5% 1/10W
R123 1-216-085-00 RES,CHIP 33K 5% 1/10W
R124 1-216-095-00 RES,CHIP 82K 5% 1/10W
R125 1-216-089-91 RES,CHIP 47K 5% 1/10W
R126 1-216-089-91 RES,CHIP 47K 5% 1/10W
R127 1-216-089-91 RES,CHIP 47K 5% 1/10W
<SWITCH>
S101 1-692-037-31 SWITCH, KEY BOARD (SHIFT)
S102 1-692-037-31 SWITCH, KEY BOARD (
/16:9)
S103 1-692-037-31 SWITCH, KEY BOARD (
;
/SYNC)
S104 1-692-037-31 SWITCH, KEY BOARD (
;
/BLUE ONLY)
S105 1-692-037-31 SWITCH, KEY BOARD (MONO/R)
S106 1-692-037-31 SWITCH, KEY BOARD (APT/G)
S107 1-692-037-31 SWITCH, KEY BOARD (COMB/B)
S108 1-692-037-31 SWITCH, KEY BOARD (F1/F3)
S109 1-692-037-31 SWITCH, KEY BOARD (F2/F4)
S110 1-692-037-31 SWITCH, KEY BOARD (ADDRESS/SAFE AREA)
*************************************************************
* A-1375-155-A HC COMPLETE PWB (14G5,BKM-10R)
****************
1-540-044-11 SOCKET, IC (ISC1)
7-628-253-35 SCREW +PS 2X8
7-688-001-01 W 2, SMALL
<CAPACITOR>
C1 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C2 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C4 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C50 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C52 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C53 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C54 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C55 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C56 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C57 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C58 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C59 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C60 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C61 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C62 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C63 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C64 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C65 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C66 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C67 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C68 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C71 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C81 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C82 1-124-635-00 ELECT 220MF 20% 6.3V
C83 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C84 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C85 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C86 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C87 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C88 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C89 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C90 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C92 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
C93 1-126-206-11 ELECT CHIP 100MF 20% 6.3V
<CONNECTOR>
CN1 1-774-534-11 CONNECTOR, IC CARD
CN2 1-506-474-11 PIN, CONNECTOR 9P
CN3 * 1-564-009-11 PIN, CONNECTOR 10P
CN4 * 1-564-005-11 PIN, CONNECTOR 6P
CN5 1-506-471-11 PIN, CONNECTOR 6P
<DIODE>
D1 8-719-158-19 DIODE RD6.2SB
D2 8-719-158-19 DIODE RD6.2SB
D3 8-719-158-19 DIODE RD6.2SB
D4 8-719-158-19 DIODE RD6.2SB
D5 8-719-158-19 DIODE RD6.2SB
D6 8-719-158-19 DIODE RD6.2SB
D7 8-719-158-19 DIODE RD6.2SB
D8 8-719-158-19 DIODE RD6.2SB
<IC>
IC1 8-759-467-21 IC HD6473258P10-EG2.0
IC2 8-759-991-19 IC PST529CMT
IC3 8-759-186-47 IC TC74VHC138F
IC4 8-759-186-63 IC TC74VHC245F
IC5 8-759-186-77 IC TC74VHC541F
IC6 8-759-186-77 IC TC74VHC541F
IC7 8-759-175-27 IC TC74VHC574F
IC8 8-759-186-63 IC TC74VHC245F
IC9 8-759-186-30 IC TC74VHC14F
IC10 8-759-186-30 IC TC74VHC14F
IC11 8-759-175-27 IC TC74VHC574F
IC12 8-759-174-16 IC TC74VHC244F
IC13 8-759-289-43 IC LTC490CS8
IC14 8-759-186-26 IC TC74VHC02F
IC16 1-810-899-11 IC MAX877CSA
IC21 8-759-186-44 IC TC74VHC125F
HB HC
