45
Chapter 2 Menu
Setting Lists of the EXTEND Menu
This section explains the setting lists displayed in the
menu.
How to read the setting lists
•For purposes of explanation, each setting list is
preceded by a menu number. These numbers are not
displayed on the screen.
For more information about the menu number, see “About
menu numbers” on page 19.
•The arrow mark (÷) refers you to another setting list
that appears after you make the setting, or to an
operation that is carried out as a result of the setting.
When there is no arrow mark, the menu does not
have any sub-list.
[C7] EXTEND menu
Enter the password (ENTER PASSWORD [C71])
When the correct password is entered, the following
item appears.
Choose the function to execute.
RE-LOAD FACTORY DATA: Restore factory
default data for the board installed in the selected
slot. ÷[C711]
MEMORY CARD: Read and write setting and
adjustment data by using the monitor memory
card. ÷[C712]
RE-START MONITOR: Restart the monitor.
÷[C713]
ADJ INT SIGNAL SETUP: Automatically adjust the
SETUP level and 100 IRE level of internal signals.
÷[C714]
[C711] RE-LOAD FACTORY DATA menu
Select a slot where a board is installed to reload
factory default data to the board.÷[C7111]
Note
Slots you can select are slot 6 and slot 7 only. When
the optional board has been installed, you can also
select slot 2.
[C712] MEMORY CARD menu
Insert the monitor memory card into the MEMORY
CARD slot and select the operation to perform.
BACK UP SYSTEM DATA: Write the data to the
monitor memory card. ÷[C7121]
RE-STORE SYSTEM DATA: Read the data from
the monitor memory card. ÷[C7122]
Notes
•Before using a monitor memory card, it must be
formatted it with the FORMAT menu ([D4]).
•System data and MEMORY CARD data ([D1])
cannot be stored on the same memory card. To store
memory card data, use another memory card.
•The BKM-12Y monitor memory card has a capacity
of 256 Kbytes. It can store either system data for up
to 8 monitors or 38 files of memory card data.
[C713] RE-START MONITOR menu
Turn the monitor off and on again automatically.
[C714] ADJUST SIGNAL menu
Adjust the SETUP level and 100 IRE level of the
internal white signal which is used with the COLOR
TEMP ADJ menu ([B]).
[C7111] RE-LOAD FACTORY DATA menu
The following message appears to confirm the data
reload operation.
DATA RESET TO
ITS FACTORY SETTING
AND MONITOR WILL RESTART
ARE YOU SURE?
OK: ENTER KEY
CANCEL: MENU KEY
OK: To continue, press the ENTER button. ÷ Resets
the data and automatically turn the monitor off and
on again.
CANCEL: To cancel, press the MENU button. ÷
Returns to the RE-LOAD FACTORY DATA
menu. ([C711])
[C7121] BACK UP SYSTEM DATA menu
While the system is writing the data, a “–” mark blinks
at the top right of the menu. (It takes some time to save
the data.)
[C7122] RE-STORE SYSTEM DATA menu
The following message appears to confirm the data
restore operation.
ALL DATA WILL BE RESTORED
ARE YOU SURE?
OK: ENTER KEY
CANCEL: MENU KEY
OK: To continue, press the ENTER button. ÷ Read
the data from the monitor memory card and
automatically turn the monitor off and on again.
CANCEL: To cancel, press the MENU button. ÷
Return to the MEMORY CARD menu ([C712]).
46
Chapter 2 Menu
Operations on monitor memory card data are
performed with the MEMORY CARD menu.
Structure of the MEMORY CARD Menu D
Monitor Memory Card Data Operations
— MEMORY CARD Menu
Overview
Main Menu Level 1 Level 2 Level 3
NEW NAME
MEMORY CARD D SAVE [D1] FILE NAME
LOAD [D2] FILE NAME
DELETE [D3] FILE NAME Confirmation message
FORMAT [D4] Confirmation message
Setting Lists of the MENU CARD Menu
This section explains the setting lists displayed in the
menu.
How to read the setting lists
•For purposes of explanation, each setting list is
preceded by a menu number. These numbers are not
displayed on the screen.
For more information about the menu number, see “About
menu numbers” on page 19.
•The arrow mark (÷) refers you to another setting list
that appears after you make the setting, or to an
operation that is carried out as a result of the setting.
When there is no arrow mark, the menu does not
have any sub-list.
D MEMORY CARD menu
Select MEMORY CARD from the menu list.
CONTROL PRESET ADJ
COLOR TEMP ADJ
SET UP
MEMORY CARD ÷[D1] to [D4]
COPY
STATUS
MAINTENANCE
KEY PROTECT OFF
Select the operation to perform. (It takes some time to
load and save the data.)
SAVE: Write data to a monitor memory card. ÷[D1]
LOAD: Read data from a monitor memory card.
÷[D2]
DELETE: Delete a file. ÷[D3]
FORMAT: Format a monitor memory card. ÷[D4]
[D1] SAVE menu
Select the name of the file to which to write data,or
create a new file name.
NEW NAME: Enter a new name (max. 20 characters).
[D2] LOAD menu
Select the name of the file from which to read data.
[D3] DELETE menu
Select the name of the file to delete.
The following confirmation message appears.
DELETE THIS FILE?
OK: ENTER KEY
CANCEL: MENU KEY
OK: To continue, press the ENTER button. ÷ The
file is deleted.
CANCEL: To cancel, press the MENU button. ÷
Return to the level 2 of the DELETE menu [D3] (File
name list).
[D4] FORMAT menu
Confirm the format operation. The following
confirmation message appears. All files will be deleted
at formatting.
ALL FILES WILL BE DELETED!
ARE YOU SURE?
OK: ENTER KEY
CANCEL: MENU KEY
OK: To continue, press the ENTER button. ÷ The
format is performed.
CANCEL: To cancel, press the MENU button. ÷
Return to the MEMORY CARD menu ([D]).
