Sony Trinitron BVM-A14F5M User Manual

1-5
BVM-A14
1-3-2. BK Board
1 Two screws
(+BVTT 3 x 8)
4 Connector assembly
(20P)
3 Blank panel (BK)
assembly
5
Cover (BK)
assembly
7 BK board
6 PWB shield (BK) assembly
CN003
CN703
CN703
CA board
CA
board
BK board
CN003
TB board
CN211
CN212
TB board
CN211
CN212
Spacer
BK
board
Z board
(Extension board)
8
Insert the Z board
into the slot.
0 Before checking each board, put the spacer
under the attached board to fix the board.
!- Install the BK board
to the Z board.
9 Extension connector
CN003
CN703
CA
board
BK board
2 Loosen
two screws.
BK Board and Z Board
(Extension board) (A-1091-210-A)
Extension Connector
