Sony Trinitron BVM-A14F5M User Manual

1-11
BVM-A14
1-3-9. C Board
CN101 (4P)
CN301 (4P)
CN702 (6P)
CN501 (4P)
CA board
Red
White
White
Black
1 Loosen
four screws.
TB board
CN213
C board
2 BK board, CA board
CN211
CN212
CN7
CN3
CN2
CN5
CN6
CN8
CN4
6 C board
5 Two harnesses
4 Remove the two claws in the
direction of the arrows A and B.
A
B
3 Remove the C board in the
direction of the arrow.
