1-6
BVM-A14
1-3-3. CA Board
7
Loosen
two screws.
TB
board
CN213
C
board
8
Four screws
(+PS 3 x 6)
9 PWB shield
(CA) assembly
0
CA
board
CN101 (4P)
CN301 (4P)
CN702 (6P)
CN501 (4P)
CA
board
Red
White
White
Black
1
Two screws
(+BVTT3 x 8)
4 Connector assembly
(20P)
CN003
CN703
CA board
BK board
CN003
CN703
CA
board
BK
board
2
Loosen
two screws.
5
Loosen
four screws.
6
Rear panel assembly
3 Blank panel (BK)
assembly
