BVM-A14
3 Screw
(+BVTP 3 x 8)
!\
Two screws
(+BVTP 3 x 8)
8 Screw
(+PSW 3 x 6)
!-
Screw
(+PSW 3 x 6)
![Two screws
(+BVTP 3 x 12)
6 Two screws
(+BVTP 3 x 8)
CN1301
CN901
CN802
CN153
CN154
CN152
CN1401
1 Two claws
2 YA board
7 YC board
5 YC insulator
!; HD board
!' Bezel assembly
9 HC board,
HC bracket
!= Bezel bracket (L)
!] HB board
4 YB board
CN1201
YA board
0 Four screws
(+BVTP 3 x 12)
Upper
Side
1-3-17. Bezel Assembly-2
