2-2
BVM-A14
. Connection Diagram
BKM-68X
(analog component input adaptor)
75Z terminator x 4
YPBPR signal generator
Y/G terminal
PB/B terminal
PR/R terminal
SYNC terminal
REMOTE
SINGLE GROUP ALL
BVM-A14
BRIGHT
CHROMA
PHASE
UP
DOWN
CONTRAST
MANUAL
MANUAL
MANUAL
MENU
ENTER
MANUAL
16:9
EXT SYNC
BLUE ONLY
R OFF
G OFF
B OFF
MARKER
CHROMA UP
MONO
APT
COMB
CHAR OFF
COLOR TEMP
