CPD-E500/E500E
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
7-4
The components identified ! marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
R449 1-216-081-00 RES,CHIP 22K 5% 1/10W
R450 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R451 1-216-115-00 RES,CHIP 560K 5% 1/10W
R453 1-216-073-00 RES,CHIP 10K 5% 1/10W
R454 1-216-129-00 RES,CHIP 2.2M 5% 1/10W
R455 1-216-097-91 RES,CHIP 100K 5% 1/10W
R456 1-216-025-91 RES,CHIP 100 5% 1/10W
[AEP]
R457 1-211-895-11 METAL 10M 10% 1/4W
R458 1-219-398-51 METAL 2.2M 5% 1W
R459 1-211-895-11 METAL 10M 10% 1/4W
R460 1-216-073-00 RES,CHIP 10K 5% 1/10W
R461 1-216-105-91 RES,CHIP 220K 5% 1/10W
R463 1-216-097-91 RES,CHIP 100K 5% 1/10W
R464 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R488 1-216-089-91 RES,CHIP 47K 5% 1/10W
R490 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R491 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
<SPARK GAP>
SG101 1-576-354-21 GAP, SPARK
SG201 1-576-354-21 GAP, SPARK
SG301 1-576-354-21 GAP, SPARK
SG401 1-576-354-21 GAP, SPARK
SG402 1-519-422-11 GAP, SPARK
<SOCKET>
SK401!1-451-499-11 SOCKET, PICTURE TUBE
<CRYSTAL>
X401 1-781-472-21 VIBRATOR, CERAMIC (8MHz)
****************************************************************************
* A-1316-443-B G BOARD, COMPLETE
[U/C for Japan-made set]
* A-1316-480-A G BOARD, COMPLETE [AEP]
* A-1316-481-A G BOARD, COMPLETE
[U/C for Mexico-made set]
***************************
1-533-223-11 HOLDER, FUSE (F601)
4-382-854-11 SCREW (M3X10), P, SW (+)
(D610, D652, D680, IC610, IC654, Q603, Q630)
<CAPACITOR>
C601 ! 1-113-513-11 FILM 1µF 20% 275V
C602 ! 1-113-513-11 FILM 1µF 20% 275V
C603 ! 1-113-900-51 CERAMIC 470pF 10% 250V
C604 ! 1-113-900-51 CERAMIC 470pF 10% 250V
C605 ! 1-113-926-91 CERAMIC 0.0047µF 250V
C606 ! 1-113-926-91 CERAMIC 0.0047µF 250V
C607 1-113-900-11 CERAMIC 470pF 10% 250V
C610 1-117-849-11 ELECT 330µF 20% 450V
C611 1-137-479-11 FILM 1µF 10% 400V
C612 1-136-169-00 FILM 0.22µF 5% 50V
C613 1-126-967-11 ELECT 47µF 20% 50V
C614 1-163-251-11 CERAMIC CHIP100pF 5% 50V
C620 1-128-990-11 FILM 27000pF 5% 800V
C621 1-104-330-91 CERAMIC 470pF 10% 1KV
C622 1-104-330-91 CERAMIC 470pF 10% 1KV
C623 1-136-171-00 FILM 0.33µF 5% 50V
C624 1-136-171-00 FILM 0.33µF 5% 50V
C625 1-136-167-00 FILM 0.15µF 5% 50V
C626 1-136-167-00 FILM 0.15µF 5% 50V
C627 1-104-330-91 CERAMIC 470pF 10% 1KV
C629 1-137-370-11 FILM 0.01µF 5% 50V
C630 1-163-005-11 CERAMIC CHIP470pF 10% 50V
C631 1-104-665-11 ELECT 100µF 20% 25V
C633 1-164-161-11 CERAMIC CHIP0.0022µF 10% 50V
C634 1-163-009-11 CERAMIC CHIP0.001µF 10% 50V
C650 1-107-656-11 ELECT 100µF 20% 250V
C651 1-107-651-11 ELECT 4.7µF 20% 250V
C652 1-128-563-11 ELECT 100µF 20% 100V
C653 1-128-581-11 ELECT 4.7µF 20% 100V
C654 1-126-943-11 ELECT 2200µF 20% 25V
C655 1-104-664-11 ELECT 47µF 20% 25V
C656 1-126-943-11 ELECT 2200µF 20% 25V
C657 1-104-664-11 ELECT 47µF 20% 25V
C658 1-126-927-11 ELECT 2200µF 20% 10V
C659 1-128-339-11 ELECT 2200µF 20% 10V
C660 1-126-967-11 ELECT 47µF 20% 50V
C661 1-107-429-11 CERAMIC 0.0022µF 10% 1KV
C662 1-137-370-11 FILM 0.01µF 5% 50V
C663 1-126-965-11 ELECT 22µF 20% 50V
C665 1-107-909-11 ELECT 47µF 20% 10V
C666 1-126-964-11 ELECT 10µF 20% 50V
C667 1-107-909-11 ELECT 47µF 20% 16V
C680 1-115-747-51 ELECT 0.0068F 20% 10V
C681 1-104-664-11 ELECT 47µF 20% 10V
C682 1-137-368-11 FILM 0.0047µF 5% 50V
C683 1-104-664-11 ELECT 47µF 20% 10V
C684 1-128-526-11 ELECT 100µF 20% 10V
C685 1-128-526-11 ELECT 100µF 20% 10V
C686 1-104-664-11 ELECT 47µF 20% 10V
C687 1-126-964-11 ELECT 10µF 20% 50V
C692 1-115-339-11 CERAMIC CHIP0.1µF 10% 50V
<CONNECTOR>
CN601*1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
CN602*1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN603*1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN650*1-564-510-11 PLUG, CONNECTOR 7P
CN652*1-564-512-11 PLUG, CONNECTOR 9P
CN653*1-564-509-11 PLUG, CONNECTOR 6P
CN654*1-564-511-11 PLUG, CONNECTOR 8P
AG
